Summary of Contents for Clinton Electronics NX3 Series
- Page 2 IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Protect the power cord from be- ing walked on or pinched particular- ly at plugs, convenience receptacles, Keep these instructions. and the point where they exit from the apparatus. Heed all warnings. Only use attachments/accessories Follow all instructions.
- Page 3 DISCLAIMER: Clinton Electronics reserves the right to change the contents of this manual without prior notice. WARNING: Changes or modifications not expressly approved by the manufac- turer could void the user’s authority to operate the equipment.
- Page 4 The camera requires periodic Stop using your camera if you find it inspection. malfunctioning. Contact an authorized technician to carry If the camera emits smoke or is unusually out the inspection. hot for a long period, a fire may be caused. Do not install the camera on a surface Do not hold plug with wet hands.
-
Page 5: Table Of Contents
TABLE OF CONTENTS ON SCREEN DISPLAY MENU ACCESSING THE OSD OSD MENU SETTINGS LENS EXPOSURE WHITE BALANCE BACKLIGHT DAY & NIGHT DPC (Dead Pixel Compensation) SPECIAL EXIT TROUBLESHOOTING... -
Page 6: On Screen Display Menu
• COLOR • B/W • EXT • DEAD PIXEL COMPENSATION SPECIAL • CAM TITLE • MOTION • PRIVACY • PARK LINE • IMAGE ADJ. • COMM ADJ • LANGUAGE EXIT • SAVE • RESET Clinton Electronics Corp. NX3 User Manual... -
Page 7: Accessing The Osd
OSD menu. CE-REMOTE use: Plug the remote into port located on the camera. Press the SETUP button to activate the OSD menu. *CE-REMOTE (sold separately) not available for every model. 0 0 2 Clinton Electronics Corp. NX3 User Manual... -
Page 8: Osd Menu Settings
‘RET’ (RETURN), which takes you back to the previous menu screen. Or you have to the option to ‘SAVE&END’, which saves current settings and exits out of the OSD Menu. 0 0 3 Clinton Electronics Corp. NX3 User Manual... -
Page 9: Lens
: Adjust to achieve the optimum level of brightness. ► IRIS SPEED : Adjusts the Iris control speed of the DC lens. If the control speed is too slow or fast, use this menu to adjust the speed. 0 0 4 Clinton Electronics Corp. NX3 User Manual... -
Page 10: Exposure
• 1/60~1/100,000 : Manually select a shutter speed. Notes • If color rolling occurs, change the SHUTTER setting to ‘FLK’. 0 0 5 Clinton Electronics Corp. NX3 User Manual... - Page 11 : Adjust the sensitivity of DWDR, the higher the value the more sensitive the DWDR. DWDR CLINTON NX3 LEVEL RETURN Notes • AGC is not adjustable when Day & Night is set to AUTO. ( - - - - ) 0 0 6 Clinton Electronics Corp. NX3 User Manual...
-
Page 12: White Balance
: Select this when the color temperature is between 4,500°K and 8,500°K • OUTDOOR : Select this when the color temperature is between 1,700°K and 11,000°K • MANUAL : Select to manually adjust the BLUE and RED color levels. 0 0 7 Clinton Electronics Corp. NX3 User Manual... - Page 13 2. When the ambient illumination of the subject is dim. 3. If the camera is directed towards a fluorescent light or is installed in a place where illumination changes dramatically, the White Balance operation may become unstable. 0 0 8 Clinton Electronics Corp. NX3 User Manual...
-
Page 14: Backlight
Use this feature to adjust the exposure of the entire image to properly expose the subject in the foreground. AREA SEL. AREA1 AREA STATE GAIN HEIGHT BLC ON WIDTH LEFT/RIGHT TOP/BOTTOM RETURN BLC OFF 0 0 9 Clinton Electronics Corp. NX3 User Manual... - Page 15 HLC performance. • In ‘NIGHT ONLY’ mode, HLC is not active during the daylight or when bright lights are not present at night. Clinton Electronics Corp. NX3 User Manual...
-
Page 16: Day&Night
Notes • When ‘AUTO’ is selected, the AGC feature is automatically disabled. • If the camera is switching back and forth between modes all the time (thrashing), increase the ‘DELAY’. Clinton Electronics Corp. NX3 User Manual... - Page 17 • IR LEVEL : Adjust the IR sensitivity. Notes • If your monitor is showing a poor image and you are using long runs of cable, setting ‘BURST’ to ON may improve the image quality. Clinton Electronics Corp. NX3 User Manual...
-
Page 18: Dpc (Dead Pixel Compensation)
(and if) they do it’s very un-economical to replace a good camera because a tiny pixel is locked permanently white, for instance. Most users will never use this feature. Clinton Electronics Corp. NX3 User Manual... -
Page 19: Special
4 direction buttons and press the SET button. 4) When position is determined, select ‘END’ and press the SET button to return to the SPECIAL menu. Clinton Electronics Corp. NX3 User Manual... - Page 20 : Adjust the height/width of the motion area. • LEFT/RIGHT TOP/BOTTOM :Position the motion area on the screen. • DEGREE : Adjusts the motion sensitivity. • VIEW : Turn ‘ON’ to highlight moving objects in pink boxes. Clinton Electronics Corp. NX3 User Manual...
- Page 21 : Left Top/Left Bottom/Right Top/Right Bottom. Determines the top and bottom positions for the lines. • F /N/T : Move the F (Far)/N (Near) ends of the lines. Adjust the T (Thickness) of the lines. Clinton Electronics Corp. NX3 User Manual...
- Page 22 • Too much or too little CONTRAST will result in the image either being too bright or too dark. • By increasing the SHARPNESS level too high, the picture may become distorted or noise may appear. Clinton Electronics Corp. NX3 User Manual...
-
Page 23: Exit
Press SET to choose from the sub menu items listed below. ► SAVE : Saves current settings and closes menu. ► RESET : Current settings are discarded and reverts all settings to the default value. Clinton Electronics Corp. NX3 User Manual... -
Page 24: Troubleshooting
TROUBLESHOOTING If you have trouble operating your camera, refer to the following table. If the guidelines do not enable you to solve the problem, contact Clinton Electronics Technical Support at 1-800-549-6393 or 815-633-1444. Problem Solution Nothing appears on • Check the power connection. - Page 25 CONTACT...
