CE-955-CAM-WD
The lightning flash with an arrowhead symbol, within an equilateral
triangle is intended to alert the user to the presence of uninsulated
dangerous voltage within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
INFORMATION - This equipment has been tested and found to comply with
limits for a Class A digital device, pursuant to part 15 of the FCC Rules & CE Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
WARNING - Changes or modifications not expressly approved by the
manufacturer could void the user's authority to operate the equipment.
CAUTION : To prevent electric shock and risk of fire hazards:
◆ Do NOT use power sources other than class 2 power.
◆ Do NOT expose this appliance to rain or moisture.
This installation should be made by a qualified service person and
should conform to all local codes.
1
High Resolution Color Wide Dynamic Dome Camera
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Clinton Electronics CE-955-CAM-WD
Summary of Contents for Clinton Electronics CE-955-CAM-WD
- Page 1 WARNING - Changes or modifications not expressly approved by the manufacturer could void the user's authority to operate the equipment. CE-955-CAM-WD CAUTION : To prevent electric shock and risk of fire hazards: ◆ Do NOT use power sources other than class 2 power.
-
Page 2: Table Of Contents
■ Contents How to Use the Camera Features ■ Menu Warnings and Precautions ■ Settings ㆍ WDR CONTROL Components ㆍ EXPOSURE ㆍ WHITE BALANCE Names and Functions of Parts ㆍ FLUORESCENT ■ LENS ㆍ D/N CONTROL ■ OSD ㆍ SHARPNESS ■... -
Page 3: Features
■ Features Warning ■ The camera requires periodic inspection. High Resolution Color for Crisp, Motion Detection Contact an authorised technician to carry out the inspection. Clear Video Since the camera detects motion without ㆍProgressive image capture any additional external sensor, you can ㆍ690TVL Effective monitor activity more efficient. - Page 4 ■ Precautions Do not drop the camera or protect Never keep the camera pointed Do not install the camera in Do not install or use the camera in an it from physical shocks. directly at strong light. extreme temperature conditions. environment where the humidity is high.
-
Page 5: Components
■ Components Names and Functions of Parts ■ ① 1. COLOR DOME CAMERA ② 2. SCREWS ④ ③ 3. INSTRUCTION GUIDE ⑤ High Resolution Color Wide Dynamic Dome Camera High Resolution Color Wide Dynamic Dome Camera... -
Page 6: Names And Functions Of Parts
■ Names and Functions of Parts Names and Functions of Parts ■ LENS : Vari-Focal DC Auto Iris Lens ① 3 AXIS BRACKET ③ Please loosen screws and fix tilted and panned position. SMPS PCB FOR DUAL POWER ④ REMOTE CONTROLLER ⑤... - Page 7 1 . D o me B a s e Mo u n t i n g - O p e n t h e c a me r a b y r o t a t i n g t h e d o me c o v e r / d e c o r a t i o n r i n g c o u n t e r - c l o c k w i s e .
-
Page 8: How To Use The Camera
■ How to Use the Camera ■ Menu ■ Settings Settings can be made using the 5 buttons located in the camera. CLINTON menu ㆍMEDIUM ㆍHIGH ㆍLOW WDR CONTROL ㆍNORMAL EXPOSURE ㆍBLC ㆍAGC ㆍSENS-UP LEFT RIGHT WHITE BALANCE ㆍATW ㆍAWB ㆍMANUAL DOWN FLUORESCENT... -
Page 9: ㆍ Wdr Control
■ How to Use the Camera CLINTON Select the functionusing Change the status using EXPOSURE WDR CONTROL MEDIUM the UP or DOWN button. the LEFT or RIGHT button. EXPOSURE.. WHITE BALANCE ATW.. CLINTON FLUORESCENT D/N CONTROL AUTO WDR CONTROL MEDIUM SHARPNESS.. -
Page 10: ㆍ White Balance
■ How to Use the Camera ● AGC (AUTO GAIN CONTROL) : In the dark situation, the higher the ● AWB : To obtain the optimum state under the current luminance levels, direct the camera to point toward a sheet of white paper and press gain level, the brighter the screen but the higher the noise. - Page 11 ■ How to Use the Camera FLUORESCENT ● AUTO : This camera has a function which automatically changes CLINTON to the appropriate mode according to lighting levels. To set up the WDR CONTROL MEDIUM switching time and switching speed for the AUTO mode press the EXPOSURE..
-
Page 12: Alarm
■ How to Use the Camera SATURATION SPECIAL When the SETUP menu screen is displayed, select 'SPECIAL' by using CLINTON the Up and Down buttons so that the arrow indicates 'SPECIAL'. WDR CONTROL MEDIUM CLINTON EXPOSURE.. WHITE BALANCE ATW.. WDR CONTROL MEDIUM FLUORESCENT EXPOSURE.. - Page 13 ■ How to Use the Camera MOTION DETECTION LINELOCK LL LIMIT 5.00% ACTIVITY THR. V-PHASE PREV. SAVE. CANCEL. PREV. SAVE. CANCEL. ㆍAdjust to the desired phase from 0 to 360. ● SETUP ALARM ZONE ● FLIP : OFF / HORIZONTAL / VERTICAL / BOTH selectable. ALARM ZONE1 SETUP HORIZONTAL ㆍWhite : MOTION ZONE Position movement...
-
Page 14: ㆍ Menu Exit Options
■ How to Use the Camera Troubleshooting ■ If you have trouble operating your camera, refer to the following table. If the guidelines do not enable you to solve the problem, contact an MENU EXIT OPTIONS authorised technician. CLINTON Problem Solution WDR CONTROL MEDIUM... -
Page 15: Specifications
■ Specifications ITEM Specifications AC24V / DC12V (Max. 170mA / 250mA) Power Consumption DC12V Only (Max. 160mA) Image Sensor PIXIM 1/3" High Sensitivity Digital Sensor Effective Pixels 758(H) x 540(V) Dynamic Range 120dB(Max), 102dB(Typical) Horizontal Resolution 690TVL Effective Min. Illumination 0.1Lux Day &...
