ELECTRICAL DISTRIBUTION LOGIC (EDL)
CONFIGURATIONS AND DIAGRAMS
ABNORMAL OPERATION CONFIGURATIONS
For the Electrical Distribution Logic configurations presented here, the
initial control positions on the Electrical System Panel are the following:
− Generator Buttons pressed;
− GPU Button released;
− Battery Selector Knobs set to AUTO position;
− Essential Power Button released;
− Bus Tie Selector Knob set to AUTO position;
− Shed Buses Selector Knob set to AUTO position;
− Backup Battery Button pressed;
− Avionics Master Buttons pressed.
NOTE: - All abnormal conditions considered below are in-flight
conditions.
- In the schematic configurations, the continuous boxes
indicate energized buses while dashed boxes indicate
deenergized buses.
REVISION 22
AIRPLANE
OPERATIONS
MANUAL
ELECTRICAL
Page
1
2-05-10
Code
01
