INSTRUCTION AND SAFETY MANUAL XTIRPA
TRAILER HITCH MOUNT SYSTEM FOR PPE
UNIVERSAL RESCUE SYSTEM
IN-8007
TO BE READ AND UNDERSTOOD BY USER PRIOR TO EACH USE
INNOVA Public Utility Products Inc.
1040 Boulevard Industriel, Granby, Québec, Canada
Tel (450) 777-1240 Fax (450) 372-9936 www.xtirpa.com
MU8007-012ENEU rev03

Advertisement

loading
Need help?

Need help?

Do you have a question about the XTIRPA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Innova XTIRPA

  • Page 1 TRAILER HITCH MOUNT SYSTEM FOR PPE UNIVERSAL RESCUE SYSTEM IN-8007 TO BE READ AND UNDERSTOOD BY USER PRIOR TO EACH USE INNOVA Public Utility Products Inc. 1040 Boulevard Industriel, Granby, Québec, Canada Tel (450) 777-1240 Fax (450) 372-9936 www.xtirpa.com MU8007-012ENEU rev03...
  • Page 2 EC DECLARATION OF CONFORMITY (English) Manufacturer established in the community: Produits de Services Publics INNOVA inc., 1040, boul. Industriel, Granby, Québec, Canada J2J 1A4 Declares that the following PPE product: IN-8007 XTIRPA Extensible vehicle hitch mount system for PPE is in conformity with the provisions of the regulation (EU) 2016/425 and complies to the standard:...
  • Page 3 The XTIRPA system was engineered to act as a supporting or anchoring structure for these uses. The XTIRPA system is one of the lightest and most ergonomic systems in its cat- egory on the market, thanks to its design and use of a technologically-advanced composite. The XTIRPA System meets the EN 795 standards: 2012 Type A, Type B, Type E and TS16415: 2013.
  • Page 4 DESCRIPTION & INTERPRETATION OF MARKING SYMBOLS This symbol is used to alert the user to a potential hazard. The safety of the worker is in jeopardy. It is imperative to follow the manufacturer’s recommendations. This symbol asks the user to read and understand the manual for this product before use.
  • Page 5 Use of the XTIRPA system in areas where environmental hazards exist may require addition- al precautions to limit the possibility of injury to the user or damage to the XTIRPA system. Hazards may include, but are not limited to: high heat, fire, flame, smoke, fumes, caustic...
  • Page 6 Plan your work program before starting. Have the required equipment, procedures and peo- ple, which must be qualified and trained on the XTIRPA system and who must have read and understood this Instruction and safety manual before using the XTIRPA system, available to do the job.
  • Page 7 XTIRPA system and does it at their sole risk, therefore waiving any and all claims, rights and recourses against the manufacturer and derived therefrom.
  • Page 8 Make sure that the support legs can support the weight at all times. a) The XTIRPA system is intended to be used as part of a personal fall arrest, work positioning, personnel riding, material handling, or rescue system for use in confined spaces and act as a support structure or anchorage.
  • Page 9 Life expectancy of the XTIRPA system and its components will be determined based on the conclusions of periodic and monthly inspections which will determine whether or not the product may remain in service.
  • Page 10 WARNING: When using a counterbalanced truck, all the instructions regarding the weights required for specific applications must be followed. (see table below) MU8007-012ENEU rev03...
  • Page 11 When lowering the removable system, it is important to slowly place the system on the ground, to avoid damaging components. k) Store the XTIRPA system in a clean and dry environment, out of direct sunlight. Avoid areas with chemical or toxic vapors, substances or environments. Do not immerse or leave in direct contact with water, as corrosion and rust may occur.
  • Page 12: Warranty

    XTIRPA system, even in the event of the fault, tort (including negligence), strict liability, breach of contract or breach of warranty, even if the Manufacturer has been advised of the possibility of such damages.
  • Page 13 The manufacturer’s instructions must be followed for proper use and maintenance of the XTIRPA system. Alterations or misuse of the XTIRPA system or failure to follow instructions may result in serious injury or death, for which the Manufacturer disclaims all warranties and liabilities whatsoever, user, owner and purchaser of the XTIRPA system waiving all claims, rights and recourses against the manufacturer and derived therefrom.
  • Page 14 Illustration 1 Illustration 2 Illustration 3 IN-2126 / IN-2204 IN-2210 IN-2003 Illustration 4 Illustration 5 Illustration 6 IN-8007 A2126-07 A2126-09 Illustration 7 Illustration 8 A2126-10 A2126-38 Illustration 9 Illustration 10 Illustration 11 A2126-21 A2126-14/A2126-33 A2305-07 Illustration 12 Illustration 13 Illustration 14 IN-2348 A2348-03 A2348-05...
  • Page 15 Illustration 18 Illustration 19 Illustration 20 IN-2517 A2126-69 IN-2525 Illustration 21 A2305-90 MU8007-012ENEU rev03...
  • Page 16 Assembly compatibility for TYPE A ↓Typical composition↓ IN-2126 ou IN-2204 IN-2210 IN-2003 Assembly with A2126-21 Assembly with IN-2348 (with or without optional accessories) - Wall installation - MU8007-012ENEU rev03...
  • Page 17 - Wall installation (cont.) - For installation on a column, use above configurations - Column installation - MU8007-012ENEU rev03...
  • Page 18 Assembly compatibility for TYPE B Assembly with A2126-14 or A2126-33 (Without extension) IN-2126 ou IN-2210 IN-2003 A2126-14 / IN-2204 A2126-33 Assembly with A2126-14 or A2126-33 (With extension) IN-2126 ou IN-2210 IN-2003 A2126-14 / A2126-29 IN-2204 A2126-33 MU8007-012ENEU rev03...
  • Page 19 Assembly on vehicle (Without extension) IN-2126 ou IN-2210 IN-2003 IN-2204 Assembly on vehicle (With extension) IN-2126 ou IN-2210 IN-2003 A2126-29 IN-2204 MU8007-012ENEU rev03...
  • Page 20 Assembly compatibility with TYPE E ↓Typical composition↓ IN-2126 ou IN-2204 IN-2210 IN-2003 Mounting with A2305-07 A2305-07 Mounting with A2305-65 A2305-07 MU8007-012ENEU rev03...
  • Page 21 ↓Typical composition (follow-up)↓ IN-2126 ou IN-2204 IN-2210 IN-2003 Mounting with A2305-07 A2305-07 Mounting with A2305-65 A2305-65 MU8007-012ENEU rev03...
  • Page 22 XTIRPA system waiving all claims, rights and recourses against the manufacturer and derived therefrom. IMPORTANT: If you have questions on the use, care or suitability of the XTIRPA system for your application, please contact the Manufacturer INNOVA Public Utility Products Inc.
  • Page 23 Make sure that the tube or other certified, approved and recom- mend adapter is locked with the locking pin. IMPORTANT: Ensure that all locking pins are firmly in place. OPERATION AND INSTALLATION OF TRAILER HITCH SYSTEM WITH UNIVERSAL WALL ADAPTER IN-2348 Make sure that all compo- nents and parts are in perfect working order and that every-...
  • Page 24 OPERATION AND INSTALLATION OF TRAILER HITCH SYSTEM WITH COUNTERBAL- ANCED TRUCK (A2305-07) Make sure that all compo- nents and parts are in perfect working order and that every- thing is functioning correctly. A. Determine the placement of the truck. B. Remove the pins from the level- ing supports and rotate them into a vertical position.
  • Page 25 OPERATION AND INSTALLATION OF TRAILER HITCH SYSTEM WITH COUNTERBAL- ANCED TRUCK (IN-2525) Make sure that all compo- nents and parts are in perfect working order and that every- thing is functioning correctly. A. Determine the placement of the truck. B. Remove the pins from the level- ing supports and rotate them into a vertical position.
  • Page 26 Use the level indicator and make sure that is right in the center of the indicator. The XTIRPA system must be placed on a hard and level surface. Do not use the XTIRPA system on soft ground, such as, but not limited to, sand, grass, gravel and pebbles. If you have any questions related to the use, maintenance or suitability of the XTIRPA system for your operations, please contact the Manufacturer, PSP INNOVA INC.
  • Page 27 OPERATION AND INSTALLATION OF TRAILER HITCH MOUNT SYSTEM WITH BALLAST SUPPORT ASSEMBLY (A2305-65) Make sure that all compo- nents and parts are in perfect working order and that every- thing is functioning correctly. A. Assemble the two parts of the tank platform.
  • Page 28 A. Insert the adapter (A2126-57), with the groove face up, into the platform’s adapter and lock with pin. B. Insert the extendable vehicle coupling system (IN-2126 / IN- 2204) into the adapter and lock with pin. IMPORTANT: Ensure that all locking pins are firmly in place. LEVELING THE TRAILER HITCH SYSTEM Remove locking pin and adjust the height of the trailer hitch so that the mast recep- tacle is in a horizontal position.
  • Page 29 WARNING: Never use a winch or lifeline for fall protection when positioned below the davit arm. WARNING: Only adaptors and brackets that are approved, certified and recommended by the manufacturer are to be used with the XTIRPA system. MU8007-012ENEU rev03...
  • Page 30 XTIRPA system. WARNING: It is important to place the XTIRPA system on a hard and level surface. Do not use the XTIRPA system on a soft surface, including, but not limited to, sand, grass, gravel and rocks.
  • Page 31 WARNING: The instruction and safety manual must be followed for proper use and main- tenance of this product. Alterations or misuse of the XTIRPA system or of any component or part thereof or failure to follow instructions may result in serious injury or death, for...
  • Page 32 IN-2003. Inspection: Inspection: Before each use, inspect Inspection: Before each use, inspect the XTIRPA System to deter- XTIRPA system to determine that it Materials: Before each use, inspect mine that it is in perfect working condition. At least once is in perfect working condition.
  • Page 33 CE ACCREDITATION LABEL CE ACCREDITATION LABEL CE ACCREDITATION LABEL Notified body’s no. Notified body’s no. Accredited standard’s no. Accredited standard’s no. Accredited standard’s no. 0082 0082 EN 795:2012 EN 795:2012 EN 795:2012 Type A Type B Type E S2324-004 revB S2305-007 revC S2337-003 revD Product standard...
  • Page 34: Ground Clearance

    CALCULATION DIAGRAM Ground Clearance: Length of the lanyard carabiner Extended length of the absorber Distance between harness buckle and feet = 4.9’ (1.5 m) Minimum safe distance = 3.3’ (1 m) Pay attention to the distance to the ground! MU8007-012ENEU rev03...
  • Page 35 MU8007-012ENEU rev03...
  • Page 36 MU8007-012ENEU rev03...
  • Page 37 NOTES MU8007-012ENEU rev03...
  • Page 38 NOTES MU8007-012ENEU rev03...
  • Page 39 MU8007-012ENEU rev03...
  • Page 40 Head Office and Manufacturing Plant Innova Public Utility Productions Inc. 1040, Boulevard Industriel Canada, Qc, Canada J2J 1A4 Phone: 450.777.1240 Toll free: 1.800.461.1937 Xtirpa is a registered trademark of Innova Public Utility Productions Inc. used under www.xtirpa.com license in Canada MU8007-012ENEU rev03...
