Installing The New Tape Drive - Exabyte 110L LTO Ultrium AUTOLOADER Field Instruction

4 I
NSTALLING THE
1. 1. 1. 1.
Figure 5
2. 2. 2. 2.
3. 3. 3. 3.
Caution
4. 4. 4. 4.
E 110L, 221L, 221L-FC
XABYTE AND
N T
EW APE
Insert the tape drive so that the handle is at the left and the fan is at the
bottom, as shown in
front of the library.
Sliding a tape drive into the library (221L shown)
Tighten the captive screw to 8.0 inch-pounds (9.2 kg-cm) of torque.
Connect the cable(s) and terminator, if used, to the new tape drive.
Note: If you are installing an additional tape drive in the 221L or 221L-FC,
refer to the 221L and 221L-FC Product Manual for information about
connecting to SCSI or Fibre Channel.
To avoid damaging the tape drive, make sure the library or autoloader is powered
off when you connect it to the SCSI bus.
Reconnect the power cord and power on the library or autoloader.
Calibration of the new tape drive occurs automatically during power on.
Do not power on the 221L or 221L-FC library with an empty
Important
drive bay. Each drive bay must have either a tape drive or a
service access cover.
D
RIVE
Figure 5. The tape drive should slide easily toward the
I R
NSTALLING OR
4 I N
NSTALLING THE EW
T D
EPLACING A APE RIVE
T D
APE RIVE
