Exabyte 110L LTO Ultrium AUTOLOADER Field Instruction page 6

3 R T D
EMOVING THE APE RIVE
2. 2. 2. 2.
Figure 4
3. 3. 3. 3.
S
EPTEMBER
6 8
OF
From the back panel, use a #2 Phillips screwdriver to release the captive
screw that secures the tape drive carrier to the library or autoloader (see
Figure 4).
Handle
Captive screw
Loosening the captive screw securing the tape drive to the library
(221L shown)
Remove the drive carrier by grasping the handle and pulling it directly out.
The drive carrier weighs 4.5 kg (10 pounds); make sure you
Important
support the bottom of the carrier as you remove it.
2003 1006159
