Removing The Service Access Cover (221L Or 221L-Fc) - Exabyte 110L LTO Ultrium AUTOLOADER Field Instruction

2 R S
EMOVING THE ERVICE
2 R
EMOVING THE
If you are installing an additional tape drive in the 221L or 221L-FC library,
follow these steps to remove the drive bay service access cover. If you are
replacing a tape drive, skip to the following
Drive."
1. 1. 1. 1.
2. 2. 2. 2.
Figure 1
S
EPTEMBER
4 8
OF
A C (221L
CCESS OVER OR
S A
ERVICE CCESS
From the back panel, use a #2 Phillips screwdriver to release the captive
screw that secures the service access cover to the library (see
When the screw is loosened, remove the service access cover, as shown in
Figure 1.
Captive screw
Removing the drive access cover
