Hardware Specifications - Barracuda CloudGen F400 C Standard Model Quick Start Manual

Barracuda CloudGen Firewall
F400 C Sub-Model .F20 Port Configuration
Label OS Notation
1 p1
2 p2
3 p3
4 p4
5 p5
6 p6
7 p7
8 p8
9 p9
10 p10
11 p11
12 p12
A1 a1
A2 a2
The CloudGen Firewall hardware appliances ship with a
connect to your firewall. To protect your network, follow the instructions for the standard
deployment.
Hardware Specifications
Warranty and Safety Instructions
Opening your Barracuda Networks appliance or removing its warranty label unless instructed to
do so by Barracuda Networks support will void your warranty and hardware support.
Networks Appliance Safety Instructions
Standard Model
Model F20
USB 2.0
F400 Revision C
Speed/Type
10/100/1000 MBit RJ45
10/100/1000 MBit RJ45
10/100/1000 MBit RJ45
10/100/1000 MBit RJ45
10/100/1000 MBit RJ45
10/100/1000 MBit RJ45
10/100/1000 MBit RJ45
10/100/1000 MBit RJ45
1 GbE Optical Fiber SFP
1 GbE Optical Fiber SFP
1 GbE Optical Fiber SFP
1 GbE Optical Fiber SFP
10 GbE Optical Fiber SFP+
10 GbE Optical Fiber SFP+
Interface
Management Port
X
Quick Start Guide. Follow this guide to
• 8x 1 GbE
• 2x 10 GbE SFP+
• 8x 1 GbE Copper
• 4x 1 GbE SFP
• 2x 10 GbE SFP+
2
