2.2.1. alphaCLICK 2 Coupling 300 bar

Fig. 5 alphaCLICK 2 coupling 300 bar
1 alphaCLICK 2 coupling 300 bar
2 Indicator ring with arrow

2.2.2. alphaCLICK 2 Cylinder Adaptor 300 bar

Fig. 6 alphaCLICK 2 cylinder adaptor 300 bar
1 alphaCLICK 2 cylinder adaptor 300 bar
The cylinder adaptor has to be screwed into a cylinder valve with a
specific torque of 20-30 Nm.
1
2
1
AirMaXX SL
DESCRIPTION
9
