1 Piece Surround Panel - Flush Wood Plus Rectangle
Compatibility
•
Flush Wood Plus Insert Rectangle
Surround Panel Sizing
Packing List
•
Panel
•
(2) Panel Mounting Brackets
Installation
1. Before installing, the insert should be in place with the flue attached. Attach the brackets as shown below,
using the screws included in the hardware pack with the insert. Make sure the brackets are flush with the
front of the convection chamber.
Page 1 of 2
(Small 96100212
Small (96100212)
Large (96100215)
17601649 - Printed 8/9/11
Large 96100215)
Height
Width
30-1/2"
42"
34"
44"
© Travis Industries, Inc.
