| ASSEMBLING THE TURNTABLE
STEP 1
Take the titanium threaded bars located in
B2 (layer B, number 2), these have already
been assembled as shown in the image and
are ready to be used.
PLEASE NOTE: Each bar has two O-rings
already installed and the nut, these should
be spaced as shown in the image below.
10mm
55mm
60mm
SIDE A
SIDE B
7
