Installation, Operation and Service Manual
Serial numbers below J62764
Following installation, please forward this manual
to the appropriate operations person.
-20 C FZR20/25–LB
-30 C FZR20/25–PL
00981795R03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FZR20-LB and is the answer not in the manual?

Questions and answers

anthony gonzales
March 19, 2025

how do i rest red indicator light on controller display

0

Related Manuals for Follett FZR20-LB

Summary of Contents for Follett FZR20-LB

  • Page 1 -20 C FZR20/25–LB -30 C FZR20/25–PL Installation, Operation and Service Manual Order parts online www.follettice.com Serial numbers below J62764 Following installation, please forward this manual to the appropriate operations person. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 www.follettice.com 00981795R03...

  • Page 2: Table Of Contents

    Cleaning ......21 Welcome to Follett..... 3 Interior cleaning .

  • Page 3: Welcome To Follett

    Before you begin After uncrating and removing all packing material, inspect the equipment for concealed shipping damage. If damage is found, notify the shipper immediately and contact Follett Corporation so that we can help in the filing of a claim, if necessary.

  • Page 4: Ambients

    Standard features – all models Door Solid, insulated, stainless steel Door handle ADA-compliant, full length handle with integral lock Interior/exterior material Heavy-duty, corrosion resistant stainless steel Casters (4) dual-wheel swiveling casters with toe locks Insulation 2.75" (7 cm) thick, CFC-free foam insulation throughout Air circulation system Ducted air through back plenum openings (16 - PL, 12 - LB) with front face return Temperature probe...

  • Page 5: Installation

    Installation DANGER • Do not tilt any unit further than 30° off vertical during uncrating or installation • Refrigeration module area contains mechanical, moving parts. Keep hands and arms clear of this area at all times. If access to this area is required, power to unit must be disconnected first. Fig.

  • Page 6: Fill Product Simulation Bottle

    Fill product simulation bottle Fig. 4 1. Remove probe and cap from the top bottle and fill with solution used at your facility (e.g., 60% glycerine and 40% water) (Fig. 4). Replace cap and reinsert probe sensor. 2. If equipped with a bottom probe, perform same procedure for bottom bottle.

  • Page 7: Remote Alarm Connections (If Desired)

    Remote alarm connections (if desired) Fig. 7 Remote communication connections are located on back side of top facade (Fig. 7). Dry contacts • Connection to NO or NC contacts provides remote alarming capability • No temperature data is communicated RS-485 port •...
  • Page 8 Fig. 9 3. Remove front left and right return louver screws to uncover access port (Fig. 9). 4. Route probe wire down either side channel in cabinet. 5. Use permagum to seal around probe wire access hole. 6. Reinstall louver screws. ACCESS PORT LOUVER SCREWS SIDE CHANNEL...
  • Page 9 Set time & date ATTENTION • The time/date are not retained in the event of a power interruption or if the batteries are dead. • Change batteries with the unit powered up. Change one battery at a time to retain time/date. Failure to follow this procedure will result in loss of time &...
  • Page 10 Change temperature display to show degrees Fig. 13 Fahrenheit (if desired) Follett has pre-set the temperature display to read in degrees Celsius. If degrees Fahrenheit display is preferred: 1. Press Menu button (Fig. 13). - 3 0 . 0 C B o t t o m Te m p - 3 0 .
  • Page 11 Fig. 17 3. Use to scroll and highlight High Alarm Set and press Enter to select (Fig. 17). H i g h A l a r m S e t - 3 0 . 0 C L o w A l a r m S e t B a c k E n t e r Fig.

  • Page 12: Alarms

    Alarms The freezer has several alarms that will sound an audible and visual alarm. Alarm type is shown on the top line of the alarm display and multiple alarms will show progressively on the display. A red LED, to the right of the display, accompanies all alarms.

  • Page 13: Alarm Volume Selection

    Alarm volume selection Fig. 22 Factory default setting is “high” . To change volume of the alarm: 1. Press Menu button (Fig. 22). - 3 0 . 0 C B o t t o m Te m p - 3 0 . 0 C M e n u Fig.

  • Page 14: Password Pin Security (Default Is 3843)

    Fig. 26 2. Use to scroll and highlight Alarm Silence and press Enter to select (Fig. 26). S e t A l a r m Vo l u m e - 3 0 . 0 C A l a r m S i l e n c e B a c k E n t e r Fig.

  • Page 15: To Make A New Password Pin

    Fig. 30 3. Use to choose ON or OFF and press Enter to select (Fig. 30). 4. Press Back until the main temperature display screen is displayed. P a s s w o r d - 3 0 . 0 C O F F B a c k E n t e r...

  • Page 16: Min/Max Temperature Logging

    E n t e r Probe calibration Fig. 37 Follett freezer probes are calibrated to a known standard prior to leaving the factory. Recalibration can be easily accomplished at any time, if desired: - 3 0 . 0 C Method 1 1.
  • Page 17 Fig. 38 4. Use to scroll and highlight Refrigeration Controls (Fig. 38). R e f r i g e r a t i o n C o n t r o l s - 3 0 . 0 C P a s s w o r d o n / o ff P I N S e t Ti m e / D a t e B a c k...

  • Page 18: Method 2

    Fig. 42 Method 2 1. Remove upper temperature probe from probe bottle and completely submerge into an ice bath. - 3 0 . 0 C Note: Ice bath should be densely compacted ice (flake, crushed, nugget, or cracked) and a little water. B o t t o m Te m p - 3 0 .
  • Page 19 Fig. 46 6. Use to scroll and highlight Refrigeration Controls (Fig. 46). R e f r i g e r a t i o n C o n t r o l s - 3 0 . 0 C P a s s w o r d o n / o ff P I N S e t Ti m e / D a t e B a c k...

  • Page 20: Chart Recorder Set Up (If So Equipped)

    (Fig. 42). A package of 50 charts that record in C is included with your freezer. If you have changed your display to show temperatures in F, you will need different charts. Please call Follett at (877) 612-5086 or +1 (610) 523-9361 to order part number 00980888.

  • Page 21: Removing Drawers

    Removing drawers Fig. 51 1. Pull drawer forward to stop (Fig. 51.1). 2. Lift drawer front to free front rollers from slides (Fig. 51.2). 3. Still lifted, pull drawer forward to free back rollers from slides. Removing slides 1. Push slides all the way back. 2.

  • Page 22: Annual Cleaning And Inspection

    Annual cleaning and inspection Fig. 54 Removal of dust and other particulates from air intake areas and the condenser is important for proper operation. Environments with large amounts of dust may require more frequent cleaning. 1. Disconnect power to unit by turning power switch off (located on upper front facade panel) and removing power cord from receptacle.

  • Page 23: Service

    The system uses a thermostatic expansion valve (TXV) metering device and is critically charged. Access fittings are not provided. Temporary piercing valves are required to work on the refrigeration system. Follett recommends that if hoses are ever connected to the refrigeration system for service, the refrigerant should be recovered, permanent access valves should be installed and the system evacuated, and recharged by weighing in the correct refrigerant charge (10.6 oz.

  • Page 24: Controller Operation

    After defrost terminates, there is a 2 minute drip time delay to allow excess condensation to drip off the evaporator coil before the compressor and condenser fan motor cycle on. The evaporator fan motor is off during defrost and is delayed an additional 4 minutes for a total delay of 6 minutes after defrost terminates before cycling on. The heat from the compressor, condenser and hot gas discharge line along with the airflow from the condenser fan evaporates any condensate in the drain pan as well as providing preliminary cooling of the high pressure vapor prior to entering the condenser.

  • Page 25: Fascia Heater Cycle

    Fig. 59 3. Press and hold Enter and together for 3 seconds (Fig. 59). C a l i b r a t i o n - 3 0 . 0 C R e f r i g S e t p o i n t D i ff e r e n t i a l H i g h S e t p o i n t L i m i t B a c k...
  • Page 26 Fig. 63 2. Use to scroll and highlight Refrigeration Controls (Fig. 63). R e f r i g e r a t i o n C o n t r o l s - 3 0 . 0 C P a s s w o r d o n / o ff P I N S e t Ti m e / D a t e B a c k...

  • Page 27: Changing Temperature Set Point

    Changing temperature set point Fig. 67 ATTENTION BEFORE MAKING ANY CHANGES TO FACTORY-DEFAULT REFRIGERATION - 3 0 . 0 C SETTINGS, CONTACT FACTORY. FACTORY DEFAULT IS IN DEGREES C. IF USER HAS CHANGED DISPLAY TO SHOW TEMPERATURE IN DEGREES F, ALL OTHER TEMPERATURES WILL DISPLAY IN DEGREES F.

  • Page 28: Defrost Settings

    Defrost Settings Fig. 71 1. Press Menu button. 2. Use to scroll and highlight Refrigeration Controls (Fig. 71). R e f r i g e r a t i o n C o n t r o l s - 3 0 . 0 C P a s s w o r d o n / o ff P I N S e t Ti m e / D a t e...
  • Page 29 Fig. 75 to scroll and highlight Defrost End Temp (Fig. 75), press Enter to view. The defrost will terminate at 5.0 C (41.0 F) evap temperature - consult D e f r o s t I n t e r v a l - 3 0 .

  • Page 30: Test Defrost/Manual Defrost

    Test defrost/manual defrost Fig. 79 1. Complete steps 1-4 in the Defrost Setting section (page 26). 2. Use to scroll and highlight Test defrost (Fig. 79). D r i p D e l a y - 3 0 . 0 C press and hold Enter and Down ( ) button To initiate a manual defrost, Te s t D e f r o s t...
  • Page 31 Controller replacement CAUTION • Controller board is susceptible to electrostatic discharge. Extreme care should be exercised by using a grounding strap when handling and installing control board. Fig. 82 1. Turn off power to unit and unplug. 2. Remove facade and disconnect electrical plugs. 3.
  • Page 32 Slide-out unit cooler Fig. 84 Follett’s slide-out refrigeration system allows technicians to remove the entire unit from the freezer top. 1. If necessary remove facade and upper side panels. 2. Remove four bolts securing unit cooler to refrigerator top (Fig. 84).
  • Page 33 Wiring diagram 115 VAC , 60 Hz φ COND FAN COMPRESSOR POTENTIAL RELAY ON/OFF START INTERIOR LINER EVAP DEFROST HEATER PAN HEATER DRAIN HEATER FASCIA HEATER TO CHART 12 VDC 0-5 VDC BACKUP RECORDER TXD + RJ11 MAGNET RS485 6P/4C TXD - DOOR SW HOT KEY...
  • Page 34 Service 00981795R03 – FZR20/25 LB, PL...

  • Page 35: Compressor Data

    Compressor Data Condenser Fan Motor Data Compressor Current Draw 0.58A RLA max 9.8A 35Ω Defrost Heater Data Compressor Ohm Ratings Evaporator Heater 3.5Ω 400 W 2.98A—4.0A 31Ω—35Ω 0.7Ω Drain Pan Heater 4.2Ω 85 W 0.63A—0.86A 148Ω—163Ω Drain Tube Heater Evaporator Fan Motor Data 15 W 0.11A—0.15A 909Ω-1005Ω...

  • Page 36: Troubleshooting

    9. Shine a flashlight into return at top. If ice is in it. accumulating, defrost completely. If problems persist after following this basic troubleshooting guide, call Follett’s technical service group at (877) 612-5086 or +1 (610) 252-7301. Troubleshooting 00981795R03 – FZR20/25 LB, PL...

  • Page 37: Appendix

    Appendix Control key functions M E N U E n t e r m a i n m e n u B a c k R e t u r n t o p r i o r B u t t o n s t o s e l e c t s c r e e n o p t i o n s E N T E R S c r o l l u p...

  • Page 38: Replacement Parts

    Replacement parts Unit cooler Replacement parts 00981795R03 – REF20/25 LB, PL...
  • Page 39 Reference Description Part # Thermal overload, evaporator heater 01002294 Not shown Thermal overload, drain pan heater 00996504 Not shown Condensate drain tube with trap 00996512 Not shown Heater, condensate drain tube 00996496 Defrost heater, drain pan 00996488 Defrost heater, evaporator (includes clips) 01002732 Evaporator cover (includes screws) 01002831...

  • Page 40: Cabinet

    Cabinet Reference Description Part # Caster, swivel with brake 00187674 Bracket, bottle, 125ML 00171132 Slide, drawer, FZR25 (set of 2) 00193045 Slide, drawer, FZR20 (set of 2) 00188367 Bottle with gasket 01015817 Shelf, FZR25 (with supports) 01015841 Shelf, FZR20 (with supports) 01015858 Pilaster (with screws) 01015866...

  • Page 41: Facade

    Facade Reference Description Part # Chart recorder 00980862 Controller 00918607 Not shown Kit, door switch 00939959 Male, bayonet (strike, snap) 00179549 Facade, locking clip 00931501 Complete facade assembly with chart recorder 00996553 Not shown Complete facade assembly without chart recorder 00996561 Facade, front cover only for units with charter recorder 00940130...

  • Page 42: Door Assembly

    Wall bracket kit, seismic anchoring 00927194 Door handle kit 00996637 Molded door handle cap, top 00989251 Molded door handle cap, bottom 00989244 Follett is a registered trademark of Follett Corporation, registered in the US. Replacement parts 00981795R03 – REF20/25 LB, PL...
  • Page 43 00981795R03 – REF20/25 LB, PL Replacement parts...
  • Page 44 Follett is a registered trademark of Follett Corporation, registered in US. 801 Church Lane • Easton, PA 18040, USA 00981795R03 Toll free (877) 612-5086 • +1 (610) 252-7301 © Follett Corporation 2/16 www.follettice.com...
