BCM MX-RPLPS User Manual

Lga 1700 socket supports intel core i7/i5/i3 processor, formerly the raptor lake ps / alder lake ps platform mini itx motherboard
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MX-RPLPS
LGA 1700 socket supports Intel® Core™ i7/i5/i3 Processor,
formerly the Raptor Lake PS / Alder Lake PS Platform
Mini ITX Motherboard
User's Manual
Ver. 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX-RPLPS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BCM MX-RPLPS

Summary of Contents for BCM MX-RPLPS

  • Page 1 MX-RPLPS LGA 1700 socket supports Intel® Core™ i7/i5/i3 Processor, formerly the Raptor Lake PS / Alder Lake PS Platform Mini ITX Motherboard User’s Manual Ver. 1.0...

  • Page 2: Table Of Contents

    1.7 Connectors ........................35 1.7.1 Rear panel connectors ..........................35 1.7.2 CPU and System fan connectors (CPU_FAN1, CHA_FAN1, CHA_FAN2) ...........36 1.7.3 System Panel (F_PANEL) ........................37 1.7.4 ATX power connectors (ATX12V1) ......................38 1.7.5 Serial Port connectors (COM1~4) ......................39 2 MX-RPLPS User’s Manual...
  • Page 3 2.4.7.1.1 Smart FAN mode Configuration ....................67 2.4.8 S5 RTC wake settings ..........................69 2.4.9 Serial Port Console Redirection ......................69 2.4.10 intel TXT information ..........................73 2.4.11 USB configuration ..........................73 2.4.12 Network Stack Configuration ........................ 76 MX-RPLPS User’s Manual 3...
  • Page 4 2.5.2.4 HD Audio Configuration ..........................87 2.5.2.5 Serial IO Configuration ........................... 88 2.5.2.6 Digital IO Configuration ..........................89 2.5.2.7 Amplifier GAIN(db) ............................89 2.6 Security ........................... 90 2.7 Boot ..........................91 2.8 Save & Exit ........................92 4 MX-RPLPS User’s Manual...

  • Page 5: Safety Information

    If you encounter technical problems with the product, contact a qualified service technician or your retailer. The symbol of the crossed out wheeled bin indicates that the product (electrical and electronic equipment) should not be placed in municipal waste. Check local regulations for disposal of electronic products. MX-RPLPS User’s Manual 5...

  • Page 6: Safety Declaration

    This device complies with the requirements in Part 15 of the FCC rules. Operation is subject to the following two conditions: ⚫ This device may not cause harmful interference. ⚫ This device must accept any interference received, including interference that may cause undesired operation. 6 MX-RPLPS User’s Manual...

  • Page 7: About This Guide

    CAUTION: Information to prevent damage to the components when trying to complete a task. IMPORTANT: Instructions that you MUST follow to complete a task. NOTE: Tips and additional information to help you complete a task. MX-RPLPS User’s Manual 7...

  • Page 8: Typography

    Command Means that you must type the command exactly as shown, then supply the required item or value enclosed in brackets Example: At the DOS prompt, type the command line: afuEfix64.efi /i[filename] afuEfix64.efi /71891100.ROM /P /B 8 MX-RPLPS User’s Manual...

  • Page 9: Packing List

    MX-RPLPS User’s Manual Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x MX-RPLPS mini-ITX ⚫ 1 x I/O Shield ⚫ 1 x SATA cable ⚫ If any of the above items is damaged or missing, please contact your retailer.

  • Page 10: Revision History

    MX-RPLPS User’s Manual Revision History Revision Revision History Date V 0.1 First Draft version August, 2024 V 0.2 Format Cleaning November, 2024 V 1.0 First release February, 2025 10 MX-RPLPS User’s Manual...

  • Page 11: Specifications Summary

    1 x Barrel Type DC-in Connector Internal I/O Connector 1 x LVDS Header 1 x JBKL1 2 x SATA III (Red) Internal I/O 1 x USB 3.2 Gen 1 Header (2 Ports) 1 x eDP Header (Optional) MX-RPLPS User’s Manual 11...
  • Page 12 5% ~ 85% Relative Humidity, Non-condensing Size (L x W) Mini ITX Form Factor 6.7"x 6.7" (170mm x 170mm) Warning! MX-RPLPS mainboard can only supports Intel (Series 1) PS processors, other processor might damage the board. https://www.intel.com/content/www/us/en/ark/products/series/236798/intel-core-processors-series-1.html 12 MX-RPLPS User’s Manual...
  • Page 13 MX-RPLPS User’s Manual Block Diagram MX-RPLPS User’s Manual 13...

  • Page 14: Chapter 1 - Product Introduction

    MX-RPLPS User’s Manual Product Introduction 14 MX-RPLPS User’s Manual...

  • Page 15: Before You Proceed

    When installing the motherboard, make sure that you place it into the chassis in the correct orientation. The edge with external ports goes to the rear part of the chassis as indicated in the image below. MX-RPLPS User’s Manual 15...

  • Page 16: Screw Holes

    Place nine (9) screws into the holes indicated by circles to secure the motherboard to the chassis. Do not over tighten the screws! Doing so can damage the motherboard. Place this side towards the rear of the chassis. 16 MX-RPLPS User’s Manual...

  • Page 17: Motherboard Layout

    MX-RPLPS User’s Manual 1.2.3 Motherboard Layout MX-RPLPS User’s Manual 17...

  • Page 18: Layout Content List

    1 x 3 header, pitch 2.00mm JLVDS_BKL1 LVDS brightness control mode 1 x 3 header, pitch 2.00mm Selection JPSON1 AT/ATX Mode Select 1 x 3 header, pitch 2.00mm RI SEL 1-2 COM power setting 12P 8.75*8.3mm Rear Panel Connector 18 MX-RPLPS User’s Manual...

  • Page 19: Central Processing Unit (Cpu)

    CPU, fan and heatsink assembly. If the instructions in this section do not match the CPU documentation, follow the latter. ⚫ Upon purchase of the motherboard, make sure that the PnP cap MX-RPLPS User’s Manual 19...
  • Page 20 Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket pins/motherboard components. BCM will shoulder the cost of repair only if the damage is shipment/transit-related. ⚫...

  • Page 21: Installing The Cpu

    To prevent damage to the socket pins, do not remove the PnP cap unless you are installing a CPU. 3. Lift the Load lever with your thumb and forefinger to around 120º angle (A), then pull the PnP cap from the CPU socket to remove (B). MX-RPLPS User’s Manual 21...
  • Page 22 (A) until it snaps into the retention tab. The CPU fits in only one correct orientation. DO NOT force the CPU into the socket to prevent bending the connectors on the socket and damaging the CPU! 22 MX-RPLPS User’s Manual...

  • Page 23: Installing The Cpu Heatsink And Fan

    Fasten the screws Fastener Motherboard hole Orient the heatsink and fan assembly such that the CPU fan cable is closest to the CPU fan connector. Make sure each fastener is oriented as shown. MX-RPLPS User’s Manual 23...
  • Page 24 Do not forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components. These are not jumpers! DO NOT place jumper caps on the fan connectors. 24 MX-RPLPS User’s Manual...

  • Page 25: Uninstalling The Cpu Heatsink And Fan

    2. Rotate each fastener counterclockwise 3. Pull up two fasteners at a time in a diagonal sequence to disengage the heatsink and fan assembly from the motherboard. 5. Rotate each fastener clockwise to ensure correct orientation when reinstalling. MX-RPLPS User’s Manual 25...

  • Page 26: System Memory

    SODIMM slots. The DDR5 SODIMM specifications enable up to 128GB per module, with maximum data transfer speeds of 6400MT/s, and operate at a reduced voltage of 1.1V for improved efficiency. 26 MX-RPLPS User’s Manual...

  • Page 27: Installing A Dimm

    DDR/DDR2/DDR3/DDR4 SODIMMs. ⚫ DO NOT install DDR/DDR2/DDR3/DDR4 SODIMMs to the DDR5 SODIMM socket. Support the DIMM lightly with your fingers when pressing the ejector tabs. The DIMM might get damaged when it flips out with extra force. MX-RPLPS User’s Manual 27...

  • Page 28: Expansion Card

    1. Turn on the system and change the necessary BIOS settings, if any. See Chapter 2 for information on BIOS setup. 2. Assign an IRQ to the card if needed. Refer to the tables on the next page. 3. Install the software drivers for the expansion card. 28 MX-RPLPS User’s Manual...

  • Page 29: Pci Express X16 Slot

    1 x M.2 E-Key 2230 (PCIe x1 Channel & USB Signal) 1 x M.2 M-Key 2280 & 2242 NVMe (with Gen 4 PCIe) 1 x M.2 B-Key 3052 & 3042 (with PCIe x2 & USB Signal) M.2 B key MX-RPLPS User’s Manual 29...
  • Page 30 MX-RPLPS User’s Manual M.2 M key 30 MX-RPLPS User’s Manual...

  • Page 31: Jumpers

    Except when clearing the RTC RAM, never remove the cap on CLRTC jumper default position. Removing the cap will cause system boot failure! Item Description Remarks Clear CMOS One 1x3 2.00mm pin header with one black, CLCMOS1 ⚫ long-tail Jump CAP 1-2(default)=Normal, 2-3= Clear CMOS ⚫ MX-RPLPS User’s Manual 31...

  • Page 32: At/Atx Power Mode Select (Jpson1)

    RI_SEL1, RI_SEL2 Standard 0.05" integrated circuit pitch ⚫ Com port voltage Smaller size makes better heat convection during PC ⚫ board wave soldering. 2-11=+12V; 1-12 (default)=Ring; 3-10=+5V (COM1, ⚫ COM3) 5-8=+12V; 4-9 (default)=Ring; 6-7=+5V (COM2, COM4) ⚫ 32 MX-RPLPS User’s Manual...

  • Page 33: Lvds Panel Voltage Selection: Jbklvol1

    Jump CAP 2-3 (default)=3.3V; 1-2=5V ⚫ 1.6.5 LVDS brightness control mode Selection: JLVDS_BKL1 Item Description Remarks One 1x3 2.00mm pin header with one black, ⚫ JLVDS_BKL1 long-tail Jump CAP 1-2 (default)=SIO control; 2-3=SMBUS control ⚫ MX-RPLPS User’s Manual 33...

  • Page 34: Com Power Setting: Ri Sel 1-2

    Standard 0.05" integrated circuit pitch ⚫ Com port voltage RI_SEL1, RI_SEL2 Smaller size makes better heat convection during ⚫ PC board wave soldering. 2-11=+12V; 1-12 (default)=Ring; 3-10=+5V ⚫ (COM1, COM3) 5-8=+12V; 4-9 (default)=Ring; 6-7=+5V (COM2, ⚫ COM4) 34 MX-RPLPS User’s Manual...

  • Page 35: Connectors

    Type C Connectors Type C devices. Display port Four Display Port Connectors (DP++, 1.4a supported) AUDIO Microphone This port connects a microphone. port (Pink) AUDIO Line-out port This port connects a headphone or a speaker. (Lime) MX-RPLPS User’s Manual 35...

  • Page 36: Cpu And System Fan Connectors (Cpu_Fan1, Cha_Fan1, Cha_Fan2)

    Do not forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components. These are not jumpers! DO NOT place jumper caps on the fan connectors. 36 MX-RPLPS User’s Manual...

  • Page 37: System Panel (F_Panel)

    Hard Disk Drive Activity LED (Pin 1-3) This 2-pin connector is for the HDD Activity LED. Connect the HDD Activity LED cable to this connector. The IDE LED lights up or flashes when data is read from or written to the HDD. MX-RPLPS User’s Manual 37...

  • Page 38: Atx Power Connectors (Atx12V1)

     Make sure that your power supply unit (PSU) can provide at least the minimum power required by your system. See the table below for details. 38 MX-RPLPS User’s Manual...

  • Page 39: Serial Port Connectors (Com1~4)

    Signal Description Signal Description Name Name Data Carrier RXD# Receive Detect Data TXD# Transmit Data Data Terminal Ready Ground Data Set Ready Request To Clear To Send Send RI or Ring No Pin 5V or Indicator MX-RPLPS User’s Manual 39...

  • Page 40: Serial Ata Connector

    SATA1 Signal Description Name Ground Transmit diff data - positive Transmit diff data - negative Ground Receive diff data - negative Receive diff data - positive Ground SATA power connector Signal Name +12V 40 MX-RPLPS User’s Manual...

  • Page 41: Usb Connectors (Usb910)

    USB connectors comply with USB 2.0 specification that supports up to 480 Mbps connection speed. Never connect a 1394 cable to the USB connectors. Doing so will damage the motherboard! The USB module is purchased separately. MX-RPLPS User’s Manual 41...

  • Page 42: Usb3.2 Connector (Usb78)

    These USB connectors comply with USB3.2 specification that supports up to 5Gbps connection speed. Signal Name Signal Name +5VSB USB2_P USB3_RX_N3 USB2_N USB3_RX_P3 USB3_TX_P4 USB3_TX_N3 USB3_TX_N4 USB3_TX_P3 USB3_RX_P4 USB2_N USB3_RX_N4 USB2_P +5VSB 1.7.9 I2C header (I2C1) Signal Name +3.3VSB I2C_SCL I2C_SDA 42 MX-RPLPS User’s Manual...

  • Page 43: 8-Bit Gpio Header (Jdio1)

    This connector provides an 8 bits input or output for general purpose. Signal Signal Name Name GPIO0 GPIO4 GPIO1 GPIO5 GPIO2 GPIO6 GPIO3 GPIO7 SMBCLK SMBDATA +3.3VSB 1.7.12 Amplifier Connector (JAMP1) This connector allow user to connect an external audio amplifier. Signal Name AMP_R- AMP_R+ AMP_L- AMP_L+ MX-RPLPS User’s Manual 43...

  • Page 44: Lvds Data Connector - 40-Pin

    1.7.14 LVDS Data Connector – 40-pin Signal Name Signal Name +3.3V_LVDS +5V_LVDS +3.3V_LVDS +5V_LVDS DDC_CLK DDC_DATA LVDSA_P1 LVDSA_P0 LVDSA_N1 LVDSA_N0 LVDSA_P3 LVDSA_P2 LVDSA_N3 LVDSA_N2 LVDSB_P1 LVDSB_P0 LVDSB_N1 LVDSB_N0 LVDSB_P3 LVDSB_P2 LVDSB_N3 LVDSB_N2 LVDSB_CLK_P LVDSA_CLK_P LVDSB_CLK_N LVDSA_CLK_N +12V_LVDS +12V_LVDS 44 MX-RPLPS User’s Manual...
  • Page 45 MX-RPLPS User’s Manual MX-RPLPS User’s Manual 45...

  • Page 46: Edp1 Connector

    MX-RPLPS User’s Manual 1.7.15 eDP1 Connector Signal Name Signal Name +3.3V_LVDS EDP_DN3 EDP_DP3 EDP_DN2 EDP_DP2 EDP_HPD EDP_DN1 EDP_DP1 EDP_DN0 BL_EN EDP_DP0 Brightness EDP_AUX_P EDP_AUX_N +12V_LVDS +12V_LVDS +3.3V_LVDS +12V_LVDS +3.3V_LVDS +12V_LVDS +3.3V_LVDS 46 MX-RPLPS User’s Manual...

  • Page 47: Espi1 Debug Header

    MX-RPLPS User’s Manual 1.7.16 eSPI1 Debug Header Signal Signal Name Name eSPI_IO0 +3.3VSB eSPI_IO1 eSPI_RST# eSPI_IO2 eSPI_CS1# eSPI_IO3 eSPI_CLK +3.3V 1.7.17 SPI Header Signal Signal Name Name VCC3 SPI_CS# SPI_CLK SPI_MISO SPI_MOSI HOLD# MX-RPLPS User’s Manual 47...

  • Page 48: Spi Header

    MX-RPLPS User’s Manual 1.7.18 Amplified Audio Header Signal Name AMP_R- AMP_R+ AMP_L- AMP_L+ 48 MX-RPLPS User’s Manual...
  • Page 49 MX-RPLPS User’s Manual This chapter tells how to change the system settings through the BIOS Setup menus. Detailed descriptions of the BIOS parameters are also provided. BIOS Step MX-RPLPS User’s Manual 49...

  • Page 50: Chapter 2 - Bios Setup

    The BIOS setup screens shown in this section are for reference purposes only, and may not exactly match what you see on your screen. Visit the system builder’s website to download the latest BIOS file ⚫ for this motherboard 50 MX-RPLPS User’s Manual...

  • Page 51: Legend Box

    <F3> to load the optimal default values. While moving around through the Setup program, note that explanations appear in the Item Specific Help window located to the right of each menu. This window displays the help text for the currently highlighted field. MX-RPLPS User’s Manual 51...

  • Page 52: Bios Menu Screen

    To access the menu items, press the up/down/right/left arrow key on the keyboard until the desired item is highlighted, then press [Enter] to open the specific menu. 52 MX-RPLPS User’s Manual...

  • Page 53: Main Setup

    Use this menu for basic system configurations, such as time, date etc. BIOS Information Displays the auto-detected BIOS information. ⚫ System Date The date format is <Date>, <Month>, <Day>,<Year>. ⚫ System Time The time format is <Hour>, <Minute>, <Second>. MX-RPLPS User’s Manual 53...

  • Page 54: Advanced Bios Setup

    Advanced BIOS Setup screen is shown below. The sub menus are described on the following pages. Proceed with caution when modifying Advanced menu settings, as incorrect values may cause system instability. Incorrect field values can cause the system to malfunction. 54 MX-RPLPS User’s Manual...

  • Page 55: Cpu Configuration

    MX-RPLPS User’s Manual 2.4.1 CPU Configuration Display CPU information and related setting ⚫ Efficient-core Information ⚫ Performance-core Information MX-RPLPS User’s Manual 55...
  • Page 56 MX-RPLPS User’s Manual ⚫ Intel (VMX) Virtualization Technology: [Enabled]/ [Disabled] ⚫ Intel Trusted Execution Technology: [Enabled]/ [Disabled] ⚫ Alias Check Request: [Disabled] ⚫ DPR Memory Size (MB): 4 ⚫ Reset AUX Content: [no] 56 MX-RPLPS User’s Manual...

  • Page 57: Power & Performance

    MX-RPLPS User’s Manual 2.4.2 Power & Performance Power management control for CPU ⚫ CPU Power Management Control ⚫ GT Power Management Control MX-RPLPS User’s Manual 57...

  • Page 58: Pch-Fw Configuration

    MX-RPLPS User’s Manual 2.4.3 PCH-FW configuration Configure Management Engine Technology Parameters ⚫ ME State: [Enabled]/ [Disabled] 58 MX-RPLPS User’s Manual...

  • Page 59: Thunderbolt Configuration

    MX-RPLPS User’s Manual ⚫ ME UnLock Control: [Lock]/ [UnLock] ⚫ Firmware Update Configuration 2.4.4 Thunderbolt configuration Thunderbolt Support: Enable or disable Thunderbolt functionality.: [Enabled]/ [Disabled] 2.4.5 Trusted Computing Security device settings MX-RPLPS User’s Manual 59...
  • Page 60 MX-RPLPS User’s Manual ⚫ TPM Device Selection: [dtpm]/[ftpm] ⚫ Security Device support [Disabled] Enable or disable BIOS support for the security device. Configuration options: [Enable] [Disable] 60 MX-RPLPS User’s Manual...

  • Page 61: Acpi Settings

    Enable or disable PCIE wake the system from S5. Configuration options: [Disabled] [Enabled] ⚫ Wake on Ring [Disabled] Enable or disable wake on ring function under ACPI S3/S4/S5. Configuration options: [Disabled] [Enabled] 2.4.6 NCT6126D Super IO configuration Provide NCT6126D super IO configuration settings MX-RPLPS User’s Manual 61...
  • Page 62 MX-RPLPS User’s Manual ⚫ WatchDog count mode [Second] WatchDog count mode Selection Configuration options: [Second] [Minute] ⚫ WatchDog Timeout value Fill watchdog timeout value, 0 means disables ⚫ ErP/EuP S5 Support [Disabled] Configuration options : [Disabled] [Enabled] 62 MX-RPLPS User’s Manual...

  • Page 63: Serial Port 1 Configuration

    Enable or Disable serial Port (COM) Configuration options: [Disabled] [Enabled] ⚫ Change Setting [Auto] Select an optimal settings for super IO device Configuration options: as below ⚫ COM Mode Select [RS232] Configure the COM port Mode MX-RPLPS User’s Manual 63...

  • Page 64: Serial Port 2 Configuration

    Configuration options: [Disabled] [Enabled] ⚫ Change Settings [Auto] Select an optimal settings for super IO device Configuration options: as below ⚫ COM Mode Select [RS232] Configure the COM port Mode Configuration options: [RS232][RS485 Half Duplex][RS422 Full Duplex] 64 MX-RPLPS User’s Manual...

  • Page 65: Serial Port 3 Configuration

    MX-RPLPS User’s Manual 2.4.6.3 Serial Port 3 Configuration ⚫ Serial Port [Enabled] Enable or Disable serial Port (COM) Configuration options: [Disabled] [Enabled] ⚫ Change Settings [Auto] Select an optimal settings for super IO device Configuration options: as below MX-RPLPS User’s Manual 65...

  • Page 66: Hardware Monitor

    MX-RPLPS User’s Manual ⚫ COM Mode Select [RS232] Configure the COM port Mode Configuration options: [RS232][RS485 Half Duplex][RS422 Full Duplex] 2.4.7 Hardware monitor Display Hardware monitor information 66 MX-RPLPS User’s Manual...

  • Page 67: Smart Fan

    MX-RPLPS User’s Manual 2.4.7.1 Smart FAN ⚫ Smart FAN Function [Enabled] Smart fan function Enable/Disabled Configuration Options : [Enabled] [Disabled][Manual]  2.4.7.1.1 Smart FAN mode Configuration Setting different FAN on this motherboard MX-RPLPS User’s Manual 67...
  • Page 68 MX-RPLPS User’s Manual ⚫ SYS_FAN1/CPU_FAN1/CHA_FAN1 FAN Target Smart FAN target temperature Configuration options: Please see below picture ⚫ CPU_FAN1/CHA_FAN1/CHA_FAN2 MIN.FAN Speed (%) CPU or Chassis Smart FAN minimum settings Configuration options: Please see below picture 68 MX-RPLPS User’s Manual...

  • Page 69: S5 Rtc Wake Settings

    MX-RPLPS User’s Manual 2.4.8 S5 RTC wake settings ⚫ Wake system from S5 [Disabled] Enabled or Disabled system wake on alarm event Configuration options: [Enabled] [Disabled] 2.4.9 Serial Port Console Redirection Display CPU configuration MX-RPLPS User’s Manual 69...
  • Page 70 MX-RPLPS User’s Manual ⚫ Console Redirection [Disabled] Enabled or Disabled COM1 Console redirection Configuration options: [Disabled][Enabled] 70 MX-RPLPS User’s Manual...
  • Page 71 MX-RPLPS User’s Manual MX-RPLPS User’s Manual 71...
  • Page 72 MX-RPLPS User’s Manual 72 MX-RPLPS User’s Manual...

  • Page 73: Intel Txt Information

    MX-RPLPS User’s Manual 2.4.10 intel TXT information Display Intel TXT information. This depends on CPU sku. 2.4.11 USB configuration ⚫ USB Mass Storage Driver Support [Enabled] MX-RPLPS User’s Manual 73...
  • Page 74 MX-RPLPS User’s Manual Enable or Disable USB Mass Storage Driver Support Configuration options: [Enabled][Disabled] ⚫ Mass Storage Devices [Auto] Mass Storage device emulation Type. “Auto” enumerates device according to its media format. 74 MX-RPLPS User’s Manual...
  • Page 75 MX-RPLPS User’s Manual MX-RPLPS User’s Manual 75...

  • Page 76: Network Stack Configuration

    MX-RPLPS User’s Manual 2.4.12 Network Stack Configuration Network Stack setting ⚫ Network Stack [Disabled] Enabled/Disabled UEFI Network Stack Configuration options: [Enabled][Disabled] 2.4.14 NVMe Configuration Display NVMe controller or Drive information 76 MX-RPLPS User’s Manual...

  • Page 77: Chipset

    MX-RPLPS User’s Manual 2.5 Chipset MX-RPLPS User’s Manual 77...

  • Page 78: System Agent (Sa) Configuration

    MX-RPLPS User’s Manual 2.5.1 System Agent (SA) Configuration ⚫ VT-d [Supported] 2.5.1.1 Memory Configuration Maximum Value of TOLUD. Dynamic assignment would adjust TOLUD automatically based on largest MMIO length of installed graphic controller. 78 MX-RPLPS User’s Manual...

  • Page 79: Graphic Configuration

    MX-RPLPS User’s Manual 2.5.1.2 Graphic Configuration Graphic configuration settings MX-RPLPS User’s Manual 79...

  • Page 80: Vmd Setup Menu

    MX-RPLPS User’s Manual 2.5.1.3 VMD setup menu 2.5.1.4 PCI Express Configuration ⚫ Detect Non-compliance Device [Disabled] Detect Non-compliance Device in PEG 80 MX-RPLPS User’s Manual...
  • Page 81 MX-RPLPS User’s Manual Configuration options: [Disabled][Enabled] MX-RPLPS User’s Manual 81...

  • Page 82: Pch-Io Configuration

    Flash Protection Range Registers(FPRR) [Disabled] Enabled Flash Protection Range Registers Configuration Options: [Disabled][Enabled] ⚫ GPIO Group Control [Disabled] Configure the digital GPIO pins Configuration Options: [Disabled][Enabled] ⚫ Amplifier GAIN(db) [15.3db] Select Amplifier GAIN value Configuration Options: [15.3db][21.2db][27.2db][31.8db] 82 MX-RPLPS User’s Manual...

  • Page 83: Pci Express Configuration

    MX-RPLPS User’s Manual 2.5.2.1 PCI Express Configuration  2.5.2.1.1 PCI Express Root Port 5(x2 M.2) ⚫ PCI Express Root Port 5 [Enabled] Control the PCI Express Port MX-RPLPS User’s Manual 83...

  • Page 84: Pci Express Root Port 9(X1 Key E)

    Control the PCI Express Port Configuration options: [Disabled][Enabled] ⚫ ASPM [Disabled] Set the ASPM level: Force L0s- Force all links to L0s State; Auto- BIOS auto configure; Disabled- Disables ASPM Configuration options: [Disabled][L1][Auto] ⚫ L1 Substates [Disabled] 84 MX-RPLPS User’s Manual...

  • Page 85: Sata Configuration

    SATA Mode Selection [AHCI] Determines how SATA controller operate Configuration options: [AHCI] ⚫ Port 1[Enabled] Enable or Disable SATA port 1 Configuration options: [Enabled][Disabled] ⚫ Port 2 [Enabled] Enable or Disable SATA port 2 Configuration options: [Enable ][Disabled] MX-RPLPS User’s Manual 85...

  • Page 86: Usb Configuration

    Enable or Disable USB standby power Configuration options: [Disabled] [Enabled] ⚫ USB78 Standby Power[Enabled] Enable or Disable USB standby power Configuration options: [Disabled] [Enabled] ⚫ USB910 Standby Power[Enabled] Enable or Disable USB standby power Configuration options: [Disabled] [Enabled] 86 MX-RPLPS User’s Manual...

  • Page 87: Hd Audio Configuration

    MX-RPLPS User’s Manual 2.5.2.4 HD audio Configuration ⚫ HD audio [Enabled] Control Detection of the HD-Audio device. Configuration options: [Disabled] [Enabled] MX-RPLPS User’s Manual 87...

  • Page 88: Serial Io Configuration

    MX-RPLPS User’s Manual 2.5.2.5 Serial IO Configuration ⚫ I2C0 Controller[Enabled] Enabled/Disabled Serial IO Controller Configuration options: [Disabled] [Enabled] 88 MX-RPLPS User’s Manual...

  • Page 89: Digital Io Configuration

    MX-RPLPS User’s Manual 2.5.2.6 Digital IO Configuration 2.5.2.7 Amplifier GAIN(db) MX-RPLPS User’s Manual 89...

  • Page 90: Security

    MX-RPLPS User’s Manual 2.6 Security ⚫ Administrator Password Set Administrator Password ⚫ User Password Set User Password 90 MX-RPLPS User’s Manual...

  • Page 91: Boot

    Configuration options: [LEGACY] [UEFI] ⚫ UEFI USB Key Drive BBS Priorities Specifies the boot device priority sequence from available UEFI USB key Drives. ⚫ UEFI Application Boot Priorities Specifies the boot device priority sequence from available UEFI Application. MX-RPLPS User’s Manual 91...

  • Page 92: Save & Exit

    Restore/Load default values for all the setup options. ⚫ UEFI: SanDisk, Partition (SanDisk) ⚫ UEFI: Built-in EFI Shell ⚫ Launch EFI Shell from the filesystem device Attempts to launch EFI shell application from one of the available filesystem devices. 92 MX-RPLPS User’s Manual...
