Edge-Core AS9926-24D Quick Start Manual

Quick Start Guide
Network Fabric Switch
AS9926-24D | AS9926-24DB
1
1. Network Fabric Switch
2.
Rack mounting kit—2 front-post brackets, 2 rear-post brackets,
20 screws, and 2 ear-locking screws
3.
Power cord
1
1. System LEDs
2.
24 x 400G QSFP-DD ports
3.
Management ports: 1 x 1000BASE-T RJ-45, 2 x 10G SFP+,
RJ-45/USB console, USB
System LEDs/Buttons
SYS/LOC: Flashing Amber (switch locator)
DIAG: Green (OK), Amber (no OS or fault)
FAN: Green (OK), Amber (fault)
PSU1/PSU2: Green (OK), Amber (fault)
RST (reset) Button
FRU Replacement
PSU Replacement
1.
Remove the power cord.
2. Press the release latch and
remove the PSU.
3.
Install replacement PSU with
matching airflow direction.
*150200002235A_R02*
Package Contents
2
Fan Tray Replacement
1.
Pull the handle release latch.
2. Remove fan tray from the
chassis.
3.
Install replacement fan with
matching airflow direction.
2
4. Ring lugs (x4) (included with DC PSUs only)
5.
Console cable—RJ-45 to DE-9
6. Documentation—Quick Start Guide (this document) and Safety
and Regulatory Information
Overview
3 5
4
4. Product label
5.
2 x AC/DC PSUs
6.
6 x fan trays
7.
2 x grounding screws
QSFP-DD LEDs
400G: 1 LED Blue
– 1 –
www.edge-core.com
3 4
6
Port LEDs
SFP+ 10G OOBF LEDs
Green (10G)
Amber (1G)
RJ-45 MGMT LED
Green (link/activity)
5 6
7
E102020-CS-R02
