User manual, Controlmini

3.8 Controls

Avoid danger of injury from falling parts!
Ensure that small children do not have access to the magnetically adhering front glass
and can't accidentally loosen it.

3.8.1 Graphical user interface

Touch the panel to operate. A brief touch of the panel is interpreted as a mouse click. A right
mouse click is obtained by a prolonged touch (approx. 3 seconds).
Text entries can be made using the Windows on-screen keyboard. This can be found in the
task bar at the bottom right. If you swipe from the right side of the screen, you can also switch
to tablet mode in the menu that appears so that the keyboard appears automatically when you
type in a text box.
Avoid damage to front glass and display!
Do not use the touch screen with sharp or pointed objects.

4 Delivery

Controlmini panel
USB flash drive: YOUVI Basic software package, Controlmini user manual
Brief instructions for commissioning the panel and software
Network connector
Network patch cable
Optionally included in scope of delivery:
Glass cover
Flush-mounted box or surface-mounted frame
Recovery USB Flash Drive
Controlmini power supply unit for the switch cabinet (recommended) or flush-mounted box
Caution
Caution
14
