Summary of Contents for PEAKnx Controlmini

  • Page 1 Controlmini User manual...
  • Page 2 PNX-002-A18-00017 These installation and start-up instructions contain the most important information for operating the Controlmini in a safe manner. Please study this manual carefully before working with the device. This applies to all persons who come into contact with the device.

  • Page 3: Warning Symbols And Signal Words Used In This Manual

    Controlmini, User manual Warning symbols and signal words used in this manual Obey warning to avoid death or serious injury Obey instructions to avoid personal injury or damage to property Note Instructions and facts to be followed Additional, useful hints...

  • Page 4: Table Of Contents

    3.1.2 Operation with the PEAKnx software YOUVI ........
  • Page 5 About PEAKnx ........

  • Page 6: Target Audience

    9.3. 2 Intended use Depending on the software used, the Controlmini serves as control unit for the entire KNX installation across rooms. It thus also serves as a status display. The device must be opera- ted within the scope of the technical data and instructions given in this manual. Keep the device away from moisture, dirt and dust to prevent damage to the device.

  • Page 7: Product Description

    Unauthorized repairs or changes to the device 3 Product description The Controlmini (short: panel) is a high-quality panel computer for wall mounting. It serves as a display and control unit for the components and installations controlled via KNX. 3.1 Software The panel can be operated both with the supplied YOUVI software and with other Windows-compatible software.

  • Page 8: Operation With Third-Party Software

    FAQs: www.peaknx.com/FAQ, topic “compatibility”. Note: PEAKnx does not guarantee the function of third-party software on the panel. Further instructions for setting up the panel can be found in the download area: www.peaknx.com/downloads#controlmini 3.2 Product features ■...

  • Page 9: Components I: Flush-Mounted Version

    Controlmini, User manual 3.3 Components I: Flush-mounted version Position Description Flush-mounted box Panel with touchscreen Glass cover...

  • Page 10: Components Ii: Wall-Mounted Version

    Controlmini, User manual 3.4 Components II: Wall-mounted version Position Description Wall-mounted frame Panel with touchscreen Glass cover...

  • Page 11: Touch Panel, Front View

    Controlmini, User manual 3.5 Touch panel, front view Position Description 4 x Intake for glass cover On/Off button 4 x screw holes for fixing the panel Volume up/down button Microphone WLAN antenna Camera 2 x USB 2.0 Touchscreen Windows Homebutton...

  • Page 12: Touch Panel, Rear View

    Controlmini, User manual 3.6 Touch panel, rear view Position Description 100 Mbit Ethernet port 2 x KNX-Wago 243-211 installation terminal Mini HDMI Micro SD slot USB 3.0 Panel power supply: 24 V DC Panel power supply: GND...

  • Page 13: Notes On The Panel's Ports

    3.7 Notes on the panel‘s ports 3.7.1 KNX terminals The KNX port is used as a KNX interface for the PEAKnx software and as a direct or IP inter- face for other server applications/KNX software. A terminal of the following specification is used for the KNX connection: KNX WAGO 243 211, conductor diameter: 0.6 - 0.8 mm.

  • Page 14: Connections For External Mouse And Keyboard

    Touchpen ■ Cleaning cloths for the touch screen Optionally included in scope of delivery: ■ Glass cover ■ Flush-mounted box or surface-mounted frame ■ Recovery USB Flash Drive ■ Controlmini power supply unit for the switch cabinet (recommended) or flush-mounted...

  • Page 15: Important Safety And Handling Information

    Controlmini, User manual 5 Important safety and handling information The Controlmini may only be installed and commissioned by qualified electricians! Observe the national regulations applicable in your country regarding installation, functional testing, repair and maintenance of electrical products! ■ Observe the „Five Safety Rules“ (DIN VDE 0105, EN 50110) and apply them correctly:...

  • Page 16: Installation And Start-Up

    The Controlmini can be mounted to the wall both flush (flush-mounted box PNX- 018-A17-00023 ) and surface-mounted (surface-mounted frame PNX-018-A18-00041). Furthermore, it is possible to mount the Controlmini with a suitable adapter frame on various flush-mounted boxes of other manufacturers. Further instructions for mounting the surface-mounted version or fixing with the help of adapters are supplied with the respective surface-mounted frame or adapter.

  • Page 17: Installation In Brickwork

    Controlmini, User manual Make a recess of H x W x D: 194 x 252 x 50 mm in the wall. Therefore, use the template provided. The flush-mounted box must later be flush with the wall. Depending on the cable position, press the circular plates at the top or bottom out of the box and insert the supplied self-sealing grommets to prevent damage to the cable.

  • Page 18: Connecting The Power Supply

    Please pay attention to the polarity. 6.3.2 Using a power supply unit in the flush-mounted box Particularly, when replacing a foreign device with the Controlmini, a power supply is often already present in the flush-mounted box. This means that mains voltage and low voltage are in the same housing and if connected incorrectly, even parts that normally only carry low voltage unintentionally carry mains voltage.
  • Page 19 Connect the mains cable to the 230 V side of the power supply unit. Grounding When using a power supply unit in the flush-mounted box of the Controlmini: Connect the grounding in the flush-mounted box. Use the supplied grounding set: ж...

  • Page 20: Connecting And Mounting The Panel

    Controlmini, User manual 6.4 Connecting and mounting the panel Avoid damage to the panel due to early commissioning! ■ Note the climatic conditions at the installation site! ■ Before switching on the mounted device, the device must have adapted to the climatic conditions at the installation site.

  • Page 21: Initial Commissioning And Operation

    7.1 Switching the Controlmini on and off Note: In the delivery state, the panel automatically logs on with the user name Controlmini without a password. After the Login, additional users can be added at any time or further settings may be changed in the Windows Settings.

  • Page 22: Setting Up The Visualization

    Tap the Windows logo on the Windows Start screen, select the On/Off icon and select the option “Shut down”. Note: In normal operating conditions, it is not necessary to switch off the Controlmini. 7.2 Setting up the visualization After commissioning, set up the visualization as described in the enclosed quick reference guide.

  • Page 23: Maintenance

    Restart the panel. ■ Attach the glass cover. 8 Maintenance The device is maintenance-free. If you have problems with the Controlmini, please do not carry out repairs yourself, but contact your distributor. Opening the unit invalidates the warranty. 8.1 Cleaning the touchscreen The glass cover and touchscreen must be cleaned regularly to ensure proper operation.

  • Page 24: Troubleshooting

    9. Troubleshooting 9.1 Touch panel stops responding If the Controlmini no longer reacts to input on the touchscreen (which may occur in rare cases following Windows updates), try to reboot the panel. If the problem persists, disconnect the panel from the power supply, as shown in 9.1.2 Disconnecting the panel from the power supply, and restart it.

  • Page 25: Disconnecting The Panel From The Power Supply

    9.2.1 Restoring the operating system from the Recovery USB flash drive (This requires an external mouse.) Note: Any personal data and additional software saved on the Controlmini will be lost when recovering the operating system. ■ Shut down the Controlmini.

  • Page 26: Technical Support

    Remove the Recovery USB flash drive. ■ Restart the panel. ■ Attach the glass cover. 9.3 Technical support If you experience problems with your Controlmini, please contact our PEAKnx Support Team: Mail: support@peaknx.com Create a Support Ticket: https://support.peaknx.com/?lang=en_US Tel.: +49-6151-279 1825...

  • Page 27: Technical Data

    Controlmini, User manual 10 Technical data Supply Power supply 24 V DC; 2,5 A Connection terminal, conductor cross rigid: 0.14 mm² - 1.5 mm² section flexible with wire end ferrule without plastic sleeve: 0.25 mm² - 1.5 mm² Power consumption...
  • Page 28 Controlmini, User manual Display Resolution 1920 x 1080 pixels Touch technology Projected-capacitive touch (PCAP) Periphery Speakers Broadband, stereo Microphone Room characteristics Webcam 5 Megapixels WLAN WiFi 2,4GHz IEEE 802.11b/g/n Bluetooth Dimensions Size of computer with panel 297 x 210 x 22.5 mm Size glass cover 297 x 210 x 0.7 mm...

  • Page 29: Subject To Change Without Notice

    Controlmini, User manual Subject to change without notice Content changes in this documentation, which serve the technical progress, are made without prior notice. This documentation has been prepared with great care and will be revised at regular intervals. Nevertheless, we cannot guarantee complete accuracy. All known errors are eliminated in new editions.
  • Page 30 Controlmini, User manual EU Declaration of Conformity This declaration applies to the following product: Product name: Controlmini Item number(s): PNX-002-A18-00017 Manufacturer: DOGAWIST Investment GmbH Otto-Roehm-Strasse 69 64293 Darmstadt Germany We declare under our sole responsibility that the mentioned product is in conformity with...

  • Page 31: About Peaknx

    25 years of experience in hardware and software development. Through a broad network of certified partners, PEAKnx also offers the associated services - from consulting to the installation and implementation of automation projects. The goal is to make home and building automation comfortable, cost-saving and future-proof through innovative solutions.
  • Page 32 www.peaknx.com...
