3.7 Notes on the panel's ports

3.7.1 KNX terminals

A terminal of the following specification is used for the KNX connection:
KNX WAGO 243 211, conductor diameter: 0.6 - 0.8 mm.
Note: The KNX fieldbus can only be used with PEAKnx software.


Note: The device cannot be used as a line coupler for KNX lines!

3.7.2 Power supply

The plug-in terminal for the voltage supply is designed for a conductor cross-section (rigid) from
0.14 mm² to 1.5 mm². The conductor cross-section (flexible) with wire end ferrule without plastic
sleeve must be in the range of 0.25 mm² to 1.5 mm².

3.7.3 Ethernet port

Note: A cable of category CAT5e is recommended for using the 100 Mbit LAN connection.

3.7.4 Connections for external mouse and keyboard

To connect additional controls to the panel, such as an external mouse or keyboard, a USB
port is available at the back of the panel. There are two additional USB ports on the panel front
under the glass cover, for example to use a USB adapter for a wireless keyboard and mouse, or
to transfer data onto the panel.
Avoid overheating of important panel components!
▪ Avoid prolonged use of power-intensive devices on the USB port
