3. PRODUCT OVERVIEW
3.4.1
OVERVIEW OF CONNECTIONS
Phase 3
Phase 2
UTP data cable inlet
with rubber seal
Inlets for
power cables
INSTALLATIEHANDLEIDING – P9
INSTRUCTION MANUAL – P9 | P9
INSIDE
VERSION 0129NM02INT01
07A2NM20ENG05
Ethernet port
Phase 1
Neutral
Earthing
Earthing pole
Power cables
clamps
