4. INSTALLATION DETAILS

The installer is responsible for selecting a cable thickness & safety components appropriate for
the specific situation and according to local regulations
Wiring advice*
Power cable size
Earthing advice*
Required nominal
input voltage at
charge point
MCB
RCD
Ethernet connection
cable requirements
Dynamic Power
Management cable
requirements
* The installer is always responsible for selecting a cable thickness appropriate for the specific situation and
according to local regulations;
** 3-phase charge point can also be connected to 1-phase. In this case the charge point can only charge on
1-phase;
*** The installer must select a suitable MCB with C-characteristic to match the amperage setting of the charge point,
taking into account MCB manufacturer specifications;
NOTE: The charge point can be set between 16 A / 20 A / 25 A and 32 A (depending on version)
INSTALLATIEHANDLEIDING – P11
INSTRUCTION MANUAL – P11 | P11
- Wire for the maximum hardware amperage under continuous load;
- Calculate with a COS-Phi of 0.8;
- Calculate with a max allowed voltage drop over the cable of 2%;
- Use shielded cable for underground wiring
Cable grommets sizes
Maximum cable terminal block
TN-system
TT-system
Single phase**
Triple phase**
C-characteristic***
30mA Type B, or 30mA Type A (Hi, Hpi, Si) in combination with appropriate
equipment that guarantees shutdown of power when a DC leakage of more than 6mA
occurs
Standard CAT5 or CAT6 Ethernet cable (UTP cable with RJ45 connectors)
Straight wired RJ11 or RJ12 (6P6C) connectors on CAT5 UTP cable (max 100m)
VERSION 0129NM02INT01
07A2NM20ENG05
Ø 10mm - Ø 22,5mm
10 mm solid wire
2
6 mm stranded wire with ferrules
2
PE-cable (PEN conductor is not allowed)
Separately installed grounding electrode
< 100 Ohm spreading resistance
230V+N +/-10% 50Hz
400V (3 x 230V+N) +/-10% 50Hz
