3. PRODUCT OVERVIEW

3.1 MOUNTING, PACKAGE CONTENTS AND REQUIRED TOOLS
Wall mounting
Installation materials
& power setting
Installation &
configuration of
accessories
INSTALLATIEHANDLEIDING – P5
INSTRUCTION MANUAL – P5 | P5
Package contents with charge point
- Charge point;
- Rubber grommets (various sizes);
- 2x Plastic spacers;
- 1x M4 x 20 mm bolt (Torx);
- 6x M4 x 12 mm bolts (Torx);
- 2x Power cable clamps;
- 2x UTP data cable inlet with rubber seal
- Dynamic Power Management module
for Dynamic Power Management
functionality;
- P1 dongle for Dynamic Power
Management functionality (black);
- QR code for WiFi connection
VERSION 0129NM02INT01
07A2NM20ENG05
Required tools & additional materials
(not provided)
- 4x 6.3mm x 70mm Self Tapping pan
head Torx screws (DIN 7981C) stainless
steel (A4);
- 4x plugs;
- 4x Stainless steel (A4) washers;
- Drill and bit;
- Torx screwdrivers (T20);
- Voltage tester;
- Tape measure;
- Spirit level
- Power cable;
- Cable mount clips;
- RCD & MCB;
- For local configuration, smartphone with
Installer app
- UTP cable (CAT5 or CAT6);
- RJ45 UTP cable crimp tool;
- RJ45 connectors;
- Network cable tester;
- For Dynamic Power Management
functionality:
- UTP cable (CAT5 or CAT6);
- RJ11 UTP cable crimp tool;
- 2x RJ11/RJ12 connectors;
