5. INSTALLATION PROCEDURE
Step 9: Clamp a RJ12 connector straight to the UTP
cable for Dynamic Power Management;
Step 10: Check if the RJ12 connectors are OKAY with a
network cable tester;
Step 11: Plug the RJ12 cable in the black P1 dongle,
which is included in the box. Plug the P1 dongle in the
Dynamic Power Management module.
Step 12: Connect it to the P1 port, as indicated in the
'3.4.2 Overview Installing Accessories' section;
If both ends of the UTP cable are properly connected to
the charge point & Dynamic Power Management module
and powered, the P1 LED will indicate whether the
connection is correct. If the P1 LED does not show any
signal, please check if the RJ12 connectors are properly
connected using a network cable tester. If the led of the
P1 port of the charge point is blue, the Dynamic Power
Management is functioning. If it is red, the P1 dongle is
forgotten. If there is no led on the P1 port, the cable is
not correctly connected.

5.5 INTERNET CONNECTION

The Internet connection can be established via WiFi or
Ethernet. For WiFi connection, follow steps of chapter 6.
For Ethernet connection:
Step 1: Pass the UTP cable through the grey rubber
cable inlet and clamp a RJ45 connector to the cable.
Step 2: Check if the RJ45 connectors are OKAY with a
network cable tester;
Step 3: Connect the UTP cable to the Ethernet port of
the charge point, as described in section section '3.4.1
Overview of Connections' and to the households router
with DHCP (or indirectly via a switch or hub).
5.7 FINISHING UP (CLOSE ENCLOSURE)
Step 1: Check and make sure that the rubber seal of the
casing is properly in place on the edge;
Step 2: Place the cover on the charge point;
Step 3: Hand-tighten the four M4 x 12mm T20 bolts
provided around the socket so that the cover closes on
the rubber seal but the rubber seal does not deform;
Step 4: Hand-tighten the other two M4 x 12 mm T20
bolts provided in the bottom of the cover;
Step 5: Turn the socket lid clockwise in the cover and
hand-tighten the M4 x 20 mm bolt provided;
Step 6: Switch on power to the charge point;
Step 7: Wait until charge point is fully started up (+/-10
minutes, the LED should be off)
INSTALLATIEHANDLEIDING – P13
INSTRUCTION MANUAL – P13 | P13
5.8 CHARGE POINT CONFIGURATION
Charge point configuration should be done after the
charge point is powered on, using the Home Charging
by NewMotion app. To configure charge point features
such as Dynamic Power Management, please follow the
instructions as desribed in chapter 6 of this installation
manual.
VERSION 0129NM02INT01
07A2NM20ENG05
