- Page 1 Instruction Manual From Version 1.2 email: service@glp.de Internet: http://www.GLP.de...
- Page 2 GLP • German Light Production (V2.1)
-
Page 3: Table Of Contents
3.3 The CODE Level.....................11 3.4 The Test Level ....................12 3.4.1 Selftest Procedure................12 3.5 Temperature Control 1..................12 Channel selection ( Overview table )..............13 Change the Lamp ....................16 5.1 Safety Rules ....................16 5.2 How to change the lamp .................17 GLP • German Light Production (V2.1) - Page 4 Maintenance the PATEND-LIGHT 1200..............20 7.1 Mirror and Optical System ................20 7.1.1 Cleaning the inside Mirror and the outside Optical System ....20 7.1.2 Cleaning the outside Optical System............21 7.2 Ventilation System ..................22 Technical Data /Overview ..................23 GLP • German Light Production (V2.1)
-
Page 5: Introduction
Introduction Illustration 1-1 GLP • German Light Production (V2.1) - Page 6 Illustration 1-2 GLP • German Light Production (V2.1)
-
Page 7: Safety Rules
Safety cables or clamps/hooks can increase the risk of an accident. 7. The installation should be done by qualified staff only. You need to pay attention to the common rules of technology that are not explicit mentioned in this manual. GLP • German Light Production (V2.1) -
Page 8: Installation
Make sure that the fan openings are not blocked by any circumstances. 2.2 Secure the Patend Light 1200 Use always safety wires to secure the 0 , connect them with the eye bolt in the slide nut and check the tight fit! GLP • German Light Production (V2.1) -
Page 9: Connectors
250V. The lamp is protected by a 5x20 T10A fuse 250V. Please see the printing on the , for more details look at the Illustration 1-1 in Chapter 1 Disconnect AC outlet before changing a fuse !!! GLP • German Light Production (V2.1) -
Page 10: The Menu Field
Adjust the figure by pressing the Data+ or Data- key. Confirm the DMX-Address by pressing the Menu key once. If there is no DMX- Signal, a (-) is flashing in the display. The DMX-Address is stored also while switching off the 0 !!! GLP • German Light Production (V2.1) -
Page 11: Read Out The Running Time Of Lamp And Unit
The life time is shown alternating with LIFE. 3.3 The CODE Level This level is accessed by authorised dealers only. In this level you can adjust all functions. Also the change of Pan/Tilt high-byte and low-byte is possible. GLP • German Light Production (V2.1) -
Page 12: The Test Level
Forward with the Data+ key. – Backward with the Data- key. 3.5 Temperature Control 1 Deviates the temperature value too much from the system standard, the lamp will turn off automatically. Reconnection can only be made by authorized dealers. GLP • German Light Production (V2.1) -
Page 13: Channel Selection ( Overview Table )
5 (yellow) 40 - 44 28 - 2C 16 – 17% bi (yellow – pink) 45 - 49 2D - 31 8) Color color 6 (pink) 50 - 54 32 - 36 19 – 20% GLP • German Light Production (V2.1) - Page 14 40 – 44 28 – 7B 16 – 17% Gobo 6 (rotation) 45 – 123 2D – 7B 18 – 49% rotation cw slow . fast 124 – 191 80 - BF 50 – 74% GLP • German Light Production (V2.1)
- Page 15 0 in Relative Movement. Therefore the Speed channels No. 5/6 must be also on DMX- [000] If you have a DMX- Value on one of these channels it is automatically on Absolute Movement. While programming circles or other movements please use the Absolute Movement. GLP • German Light Production (V2.1)
-
Page 16: Change The Lamp
• Install the lamp with the filler to the right direction. (see Illustration 5-1) • Distance between lamp and lens holder must bee min. 5mm. • Close the 0 before you connect the AC power! Illustration 5-1 GLP • German Light Production (V2.1) -
Page 17: How To Change The Lamp
10.Unscrew the HMI lamp nuts and change the lamp. The lamp filler must be placed like in the illustration !!! 11.Close the 0 in reverse order. Attention: Make sure that the optical slide in fits in both grooves !!! Illustration 5-2 GLP • German Light Production (V2.1) -
Page 18: Change The Gobos
10. Remove the little claps which holds the Gobos with a little screwdriver. 11. Change the Gobos and mount the claps aback to its position. Please make sure, that the Gobo fits correct. 12. Close the 0 in reverse order. GLP • German Light Production (V2.1) - Page 19 Illustration 6-1 Attention: Make sure that the optical slide in fits in both grooves !!! If you use Glass-Gobos make sure that the mirror side looks towards the lamp side. GLP • German Light Production (V2.1)
-
Page 20: Maintenance The Patend-Light 1200
Maintenance the PATEND-LIGHT 1200 The cleaning of the inner optical System, color filters, color correction filter and lenses should be done by qualified person only! Contact your local GLP Dealer for details. Use no strong detergents, acid etc. for cleaning the case. -
Page 21: Cleaning The Outside Optical System
3. Remove Sub-D socket by pressing the safety clips. Hang out the safety loop and lift the head plate cautiously. 4. Unscrew the two screws of the aperture. 5. Clean the lenses inside 6. Close the GLP • German Light Production (V2.1) -
Page 22: Ventilation System
7.2 Ventilation System Illustration 7-3 It is necessary to clean the fan openings, air channels and fan gratings on a regular base (depending on the local environment). GLP • German Light Production (V2.1) -
Page 23: Technical Data /Overview
• Angle of spread 16° • weight 32 kg • Dimensions: 566 x 434 x 395 mm • ROTO-Head Min. 1 round per 8 minutes Max. 7 rounds per second 0,02 degrees resolution 14.00/25.000 Microsteps/360 GLP • German Light Production (V2.1) - Page 24 GLP • German Light Production (V2.1)
