ENGLISH
66102 / 01
Required tools
Ruler
Phillips screwdriver
Existing key
Kevo Support: www.weiserlock.com/kevo/support
USA: 1-800-677-5625 • Canada : 1-800-501-9471
Kit "A"
Mounting plate
Adapter
Interior assembly
screws
Mounting plate
Interior cover
screws
screws
Interior cover
Parts in the box
Kit "B"
Mounting plate
Adapters
Interior assembly
screws
Mounting plate
Interior cover
screws
screws
Interior assembly
1 / 13
Kit "C"
Mounting plate
Mounting plate
screws
Battery pack
Installation and
User Guide
Adapters
Interior assembly
screws
Interior cover
screws
AA batteries
© 2016 Spectrum Brands, Inc.
Advertisement
Related Manuals for Weiser kevo convert 66102/01
Summary of Contents for Weiser kevo convert 66102/01
- Page 1 Installation and ENGLISH User Guide 66102 / 01 Required tools Parts in the box Kit “A” Kit “B” Kit “C” Mounting plate Mounting plate Mounting plate Adapters Adapter Adapters Ruler Interior assembly Interior assembly Interior assembly screws screws screws Mounting plate Interior cover Mounting plate Interior cover...
- Page 2 Make sure your existing deadbolt is compatible. If you have a standard deadbolt mounted separately from the handle below it, it is compatible with Kevo Convert. Compatible Not Compatible Not Compatible Not Compatible Mortise Integrated Lock Lock Interior Measure the thickness of your door. Measure to confirm that your door is either 35 mm or 44 mm (1-3/8"...
- Page 3 What shape is your torque blade (the part sticking out through the latch)? D-shape Vertical rectangle Slanted rectangle Horizontal rectangle Weiser and Kwikset deadbolts: Baldwin Estate deadbolts: Schlage deadbolts: Schlage deadbolts: Use kit “A” for your door. Use kit “B” for your door.
- Page 4 Install the mounting plate and test your latch. Place the mounting plate on the door so that the torque Secure the mounting plate with the mounting screws. blade inserts through the center hole. Keep parallel to the edge of the door. Black Components Only: To determine which mounting screws to use, test one of...
- Page 5 Install the interior assembly. Prepare the interior assembly. Make sure the Remove the battery pack. Remove the Make sure shaft is oriented turnpiece is in the interior cover. as shown. If needed, rotate vertical position. the shaft to this position. Stripe should be vertical.
- Page 6 Install the interior assembly (continued). SCHLAGE DEADBOLTS ONLY: Look at your mounting plate. Is your latch bolt to the left or right of your mounting plate? Left Right No adjustment is required. On your interior assembly, flip switch #2 Proceed to the next page. to the top position.
- Page 7 Install the interior assembly (continued). Install the interior assembly onto the mounting plate. Align the adapter with Secure with the torque blade. two (2) interior assembly screws. Schlage deadbolts only: You may need to rotate the adapter to align with the torque blade. bottom hole Kevo Support: www.weiserlock.com/kevo/support 7 / 13...
- Page 8 Perform the door handing process. This step will teach the lock the orientation of your door and is crucial for lock operation. Install 4 AA batteries in the battery pack. IMPORTANT: Make sure the door is open. Insert the battery pack while PRESSING AND HOLDING the Program button.
- Page 9 Download the Kevo app and set up your smartphone. Download the Kevo app at weiserlock.com/kevo/app or scan the QR code below. Follow the instructions inside the app to create an account, enroll your first smartphone and send eKeys to family and friends. Kevo Support: www.weiserlock.com/kevo/support 9 / 13 ©...
- Page 10 Install the interior cover. Important information about the interior cover: The interior cover will be If the window is unlocked, secured by three screws it can slide up for more to prevent someone convenient access to from removing the programming buttons window battery or tampering with while the cover is installed.
- Page 11 Kevo Convert Compatibility Chart Kevo Convert is compatible with the following models: Weiser Kwikset Baldwin Prestige Baldwin Reserve Baldwin Estate Schlage Deadbolts Deadbolts Deadbolts Deadbolts Deadbolts Deadbolts GD9471 All single cylinder deadbolts 8011 B360N GDC9471 8031 B560P GCD9471 660M 8041...
- Page 12 Reference Guide Kevo Convert at a Glance Kevo-Compatible Devices Smartphones and Smart Devices turnpiece shaft can be used Only use to reset Kevo A Kevo-compatible smartphone (or to manually lock and unlock Convert to delete all eKeys other mobile internet-connected Reset button the door.
-
Page 13: Advanced Features
Advanced Features History Log Kevo Plus A history of the lock’s activity may be viewed through the Kevo app With Kevo Plus, you will be able to lock and unlock your home and check whether your or by logging into the web portal: www.mykevo.com. door is locked or unlocked when you are away from home.
