5 Install the mounting plate and test your latch.
A
Place the mounting plate on the door so that the torque
blade inserts through the center hole.
Note: A D-shaped torque blade is shown, but installation is the same for all models.
C
Insert your key and test the latch for smooth operation.
If the latch does not
extend or retract
smoothly, adjust the
mounting screws.
Kevo Support: www.weiserlock.com/kevo/support
USA: 1-800-677-5625 • Canada : 1-800-501-9471
torque blade
4 / 13
B
Secure the mounting plate with the mounting screws.
Keep parallel to the
edge of the door.
Tighten
screws evenly.
D
Remove your key and make sure the bolt is fully extended.
Black Components Only: To
determine which mounting
screws to use, test one of
the thicker screws first.
If the thicker screw fits, continue
installing the thicker screws.
If the thicker screw doesn't fit,
install the thinner screws.
fully
extended
