6 Install the interior assembly (continued).
C
Install the interior assembly onto the mounting plate.
a
Align the adapter with
the torque blade.
Schlage deadbolts only:
You may need to rotate
the adapter to align
with the torque blade.
Kevo Support: www.weiserlock.com/kevo/support
USA: 1-800-677-5625 • Canada : 1-800-501-9471
b Secure with
two (2) interior
assembly screws.
7 / 13
bottom hole
