Weiser SMARTCODE 10 Installation Manual

61041 / 02
GED1800
Installation Guide
Required Tools
Use and programming
instructions are located on the
Additional Tools (depending on application)
reverse side of this document.
3
Adjust the backset of latch (if needed)
A B
Hold the latch in front of the If the latch holes are
door hole, with the latch face centered in the door hole, no
ush against the door edge. adjustment is required.
Proceed to step 4.
If the latch holes are NOT
centered, adjust latch. See
"Latch Adjustment."
A / A2
Latch Adjustment (only if needed)
180°
7
Disassemble interior assembly and load battery pack
A B C
M
M
turnpiece shaft is
rotated as shown.
K
K
Make sure
turnpiece is in the
vertical position.
D E
AA 4x
L
L
K
Ensure correct polarity. For best
results, use new non-rechargeable
Alkaline batteries only.
11
Install strike
Longer screws install
closest to door jamb.
B
B1 (2x)
B2 / B3
(2x)
Parts in the Box
Latches and Strikes Exterior Assembly
A B
C
A2
E
D
F
B1
G
B2
B3
4
Install latch
For doors with chiseled edge
A
B
A C (2x)
C
8
Perform the Inclusion process (Z-Wave locks only)
"Inclusion" refers to the process in which the lock is added to a Z-Wave or ZigBee controller.
Make sure
ZigBee locks: Perform the Inclusion process after installation is complete.
See "Z-Wave and ZigBee Systems" on the reverse side of this document.
A B
Hold the interior assembly a maximum of 12" (305 mm) from your Z-Wave
controller, and initiate the Inclusion process at the controller. Refer to your
Z-Wave control system instructions for more information.
Press button "A" on the lock one time to include it in your system. The
controller and lock must remain stationary for a total of 60 seconds during
the Inclusion process.
L
Button
12"
"A"
305 mm
Do not install
battery pack yet!
If Inclusion is unsuccessful, initiate the Exclusion process at the controller,
then press button "A" on the lock one time. Once the lock is fully excluded
from the system, repeat the Inclusion process.
12
Program the lock
Programming
instructions are
located on the
reverse side of
this document.
1
Check dimensions
Interior Assembly
L 2-3/8" (60 mm)
2-3/4" (70 mm)
M
J
1-1/2" 2-1/8"
or
38 mm 54 mm
K
Additional door preparation may be
required for doors with 1-1/2"
(38 mm) holes. Consult the drilling
instructions at www.weiserlock.com.
N P
H
Q R
5
Prepare exterior keypad
For doors with 2-1/8" (54 mm) holes
For doors without chiseled edge
2-1/8"
54 mm
A2
For doors with 1-1/2" (38 mm) holes
1-1/2"
38 mm
D
wood
block
9
Install interior assembly
A
K J
C
L
C
Z-Wave
Controller
13
Install the battery cover and re-key the lock
A B
R
K
ball tip
M
Keep "R" in a safe place, as you will
need it to access the back panel for
additional programming.
2
or
1-3/8" — 1-3/4"
35 mm — 44 mm
1"
25 mm
6
A
Make sure "F" is
installed on "E"
E
F
C
Remove and
F
discard "F"
E
Tighten
F
screws
evenly
10
B
align
A Press and hold the
Lock button while
installing battery
pack (L).
Hold button until the
Ensure tight cable
Lay excess cable at inside the
latch bolt starts
connection. bottom of the interior housing.
moving on its own.
D
N (2x)
Template
C
If your door requires drilling, cut out the template and place it on the exterior side of the door.
Complete door drilling instructions are available on the SmartCode deadbolt page of www.weiserlock.com.
G
P (3x)
If needed, re-key the
lock to work with your
existing key. See the
supplied SmartKey
Re-key instructions for
more information.
Determine required latch and extend latch bolt
For doors with chiseled edge For doors without chiseled edge
A A2
Install keypad and mounting plate
B
Route cable
through center
J
hole, then push
cable into
E bottom hole.
Cable goes
underneath
latch
D
H
Keep parallel to
Insert key and test latch. If
edge of door
latch does not extend or
retract smoothly, adjust
screws (Q).
Remove key when nished
Q
and make sure the latch
bolt is fully extended.
Q (2x)
Perform door handing process
This step will teach your lock the orientation of your door
and is crucial to lock operation.
B
L L
Did the latch bolt retract
and extend on its own
when the battery pack
was installed?
YES NO
HOLD
Door handing process Remove battery pack,
was successful! wait 15 seconds, then
Proceed to Step 11 attempt the process
after latch bolt stops again.
latch bolt
moving.
Edge Face
Fold
Centerline
2-3/8" (60 mm)
2-3/4" (70 mm)
Backset
