Operation

General Operation

WARNING : This electric firebox must be properly installed before it is used.
!
NOTE: The element retains heat after shutdown. When the heat is turned Off, there is a 5-minute cool down period
before the fan shuts off completely.
!
NOTE: The fireplace will retain the previously used settings after a power interruption.

Hidden Touch Controls

The hidden touch controls are located on the upper right of the fireplace. (Figure 18)

Remote Operation

The fireplace is supplied with a multi-function IR remote control. (Figure 19)
!
NOTE: To operate correctly, the remote control must be pointed towards the front of the unit.

App

The fireplace is capable of being controlled using the Flame Connect app for mobile devices. For up to date
information about the app, please visit www.dimplex.com/fcapp
Figure 18
Standby
Flame Effect
Flame Color
16
Press to turn on the unit or to put it in Standby mode.
When the unit is turned back on, it will retain the previously used settings.
Press to turn the flame effect on or off.
Press repeatedly to cycle through the 7 different flame themes:
1 - Base with orange and blue accents
2 - Base with orange accents
3 - Base with blue accents
4 - Blue
5 - Orange
6 - Base
7 - Orange and blue
Figure 19
