Depth:
Weight:
Shipping Weight:
Operating Ambient Temperature:
Exhaust:
Oxygen Output:
Cabinet:
CE marked models:
Electrical:
Placement:
Tubing:
Relative Humidity:
Time of Operation:
Recommended Storage and Shipping
Temperature:
Part No 1118396
36.5 cm ± 1 cm (14 3/8 in. ± 3/8 in)
For IRC5LXO2AW - 23.6 kg ± 1 kg (52 lbs ± 2 lbs)
For IRC9LXO2AWQ - 24.0 kg ± 1 kg (53 lbs ± 2 lbs)
For IRC5LXO2AW - 26.8 kg ± 1 kg (59 lbs ± 2 lbs)
For IRC9LXO2AWQ - 27.2 kg ± 1 kg (60 lbs ± 2 lbs)
10°C - 35°C (50°F - 95°F) at 20-60% relative humidity
Less than Ambient +19°C (+ 35°F)
Less than Ambient (+ 4°F) +2°C.
Impact Resistant flame-retardant plastic cabinet that conforms
to UL 94-V0.
IRC5LXO2AW, IRC9LXO2AWQ
No extension cords.
No closer than 7.5 cm (3 inches) from any wall, furniture,
draperies, or similar surfaces.
For IRC5LXO2AW 2.1 m (7 ft) cannula with a maximum 15.2 m
(50 ft) of Crush-Proof Tubing (DO NOT pinch).
For IRC9LXO2AWQ - Recommended use up to 15.2 m (50 ft)
high flow tubing with high flow cannula at all flow rates.
20 to 60%
Up to 24 hours per day
-29°C to 65°C (-20°F to 150°F) at 15-95% relative humidity
9
SPECIFICATIONS
Platinum Oxygen
®
