SECTION 23—LEAK TEST

For 5 Liter Models with Throttle Muffler and 9 Liter Models

4-Way Valve

Hose fitting on Bottom Center Port

of 4-way Valve (Located BEHIND

Exhaust Tubing)(STEP 6b)

NOTE: Only the 5 Liter model shown for clarity. The

Exhaust Tubing

Leak Test is performed in the same manner for the

Platinum 9 Liter.

FIGURE 23.1 Leak Test

Platinum

Oxygen

Part No 1118396
