Circular Shape PE Valve
Tie-Wraps
PE Valve
Terminals
Rectangular Shape PE Valve
Tie-Wraps
PE Valve
Terminals
Circular Shape PE Valve
NOTE: Depending on the date of manufacture, the unit will be equipped with one of the two
PE valve assemblies shown above, circular shape or rectangular shape.
Part No 1118396
PE Valve
Tubing
PE Valve
Tubing
"Out" Port
Barb
FIGURE 8.1 Replacing PE Valve
"Out" Port
Barb
PE Valve
Assembly
Sieve Beds
(Shown for Reference)
Rectangular Shape PE Valve
Flow Arrow
39
SECTION 8—PE VALVE
Spade Connectors
®
Platinum
Oxygen
