SECTION 7—COMPRESSOR
NOTE: Refer to Recycling Information following local governing ordinances and recycling plans
regarding disposal of the concentrator or components.
To prevent electrical shock, ALWAYS disconnect concentrator from electrical
outlet before servicing.

Replacing Compressor Assembly for 5 Liter Models

1. Turn power Off (O) and unplug the unit.
2. Remove cabinet. Refer to Removing Cabinet on page 25.
3. Loosen clamp and disconnect intake hose and heat exchanger brass nut from
compressor assembly.
4. Remove heat exchanger clamp screw from the compressor assembly.
5. Remove compressor wires from wire clamps and tie-wraps. Disconnect motor
connector from the main harness connector.
NOTE: Motor connector goes through grommet before reaching the main harness connector.
6. Remove protective boot on capacitor.
7. Disconnect capacitor wires from the top of the capacitor.
NOTE: Re-use the protective boot if the replacement parts DO NOT provide one.
8. Remove mounting screws that secure the compressor restraint bracket and remove the
bracket.
9. Lift heat exchanger, tilt compressor assembly toward front of unit and lift out.
10. Reverse STEPS 3-7 to install new compressor assembly.
11. Run unit and inspect for leaks. Refer to Leak Test on page 71.
12. If no leaks detected, turn power Off (O) and unplug the unit.
13. Reinstall cabinet. Refer to Removing Cabinet on page 25.
Part No 1118396
