SECTION 20—4-WAY VALVE
Sieve Bed Hoses
Tie-Wraps
Valve Pilot
Spade Connectors
Manifold Assembly
Adjustment Clamp
4-Way Valve
Y-tube Muffler Assembly
Valve Manifold
Input Hose
DETAIL "A" - MANIFOLD
Tie-Wrap
ASSEMBLY
Mounting
Throttle
Screw
Muffler
Washer
Bushing
(Two [2]
per side)
Sound Box
Top
FIGURE 20.2 Replacing Manifold Assembly - 5 and 9 Liter Models
63
®
Part No 1118396
