Collectors Cabinet
Assembly Instructions
355/3932 D
- Please keep for future reference
Dimensions
Width - 75cm
Depth - 10cm
Warning: 2 persons assemble recommended.
Height - 75cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 1 - 15/09/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos 355/3932 D
Summary of Contents for Argos 355/3932 D
- Page 1 Collectors Cabinet Assembly Instructions 355/3932 D - Please keep for future reference Dimensions Width - 75cm Depth - 10cm Warning: 2 persons assemble recommended. Height - 75cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not the product, this could cause recommend the components and tools listed on pages 2.
- Page 3 Components - Panels Please check you have all the panels listed below Top panel Side panel x 2 (750 x 97mm) (720 x 97mm) Glass door x 2 (725 x 410mm) Door stopper Glass shelf x 5 Bottom panel (709 x 78mm) (750 x 97mm) Rear panel (folded) (745 x 745mm)
- Page 4 Assembly Instructions Step 1 Untaped edges. Position Panels as illustrated, half-tighten with Screws Measure the distance cross corners as shown, make sure the dimention X is equal to dimention Y, then tighten up all screws. Step 2 Unfolder Rear panel and locate on the edges of Panels as shown.
- Page 5 Assembly Instructions Step 3 Locate Metal plates to the pre-drilled holes as shown, secure with Screws , make sure the metal plate do not stand over the edges. Turn the unit upright. Step 4 2 people needed for this step. Decide upon the position to be fixed.
- Page 6 Assembly Instructions Step 5 Insert the shelf holders into the holes in Side panels at desired height. Step 6 Push one glass shelf into the top level shelf holders, secure the screw underneath the shelf holder as shown. Repeat this step to locate and fix other glass shelves one by one from top to bottom for...
- Page 7 Assembly Instructions Step 7 2 people needed for this step. Position one glass door with handle hole on To inner groove. the right side as shown. Insert the top edge of glass door in the INNER groove in top panel, holding the door and insert the bottom edge into the INNER groove in...
