Grafton 5ft Bed
Assembly Instructions
Dimensions
Width - 163,5cm
Depth - 214,5cm
Height - 120cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the
- Please keep for future reference
Customer Helpline: 03456 400 800
360/9109
352/2365
Issue 1 - 24/11/14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Grafton 360/9109 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Grafton 360/9109

  • Page 1 Grafton 5ft Bed Assembly Instructions - Please keep for future reference 360/9109 352/2365 Dimensions Width - 163,5cm Depth - 214,5cm Height - 120cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800 Issue 1 - 24/11/14...
  • Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly . Check you have all the Assemble on a soft level We do not components and tools listed on surface to avoid damaging the recommend the unit or your floor.
  • Page 3 Components - Panels Please check you have all the panels listed below 01 Headboard 04 Central Support (163,5 x 120cm) (204,5 x 6cm) 02 Footboard 05 Support Foot (29 x 6cm) (163,5 x 43,5cm) 06 Slats x 24 03 Side rails x 2 (200 x 11,5cm) (75,5 x 6,9cm)
  • Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 03456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
  • Page 5 Assembly Instructions Step 1 Fitting dowels Insert dowels into the indicated parts. Step 2 Assembling side rails: 1st: Screw headless bolt to footboard 2rd: Insert washers the side rails and fit footboard to side rails. Fix headless bolts using nuts and spanner Caution: Assembling of...
  • Page 6 Assembly Instructions Step 3 Assembling side rails: Attach side rails to the headboard. Insert half moon nut into side rails as shown. Then fix them to the headboard using bolts and allen key Step 4 Fixing support foot: Fix support foot central support using bolt...
  • Page 7 Assembly Instructions Step 5 Fixing L shaped bracket: Fix L shaped brackets into pre-drilled holes in the headboard footboard using screws as shown. Step 6 Fixing central support: Fix central support to L shaped brackets in headboard footboard using bolts and nut as shown.
  • Page 8 Assembly Instructions Step 7 Fixing slats: Centralize s lats in bed frame prior to fixing. Fix slats using screws shown. Fix slats in one side first, then fix them in the other side by pushing the rail against the slats if necessary.
