- Page 1 AIER1000 series Artificial Intelligence Education Solution User’s Manual Version 1.0 (June 2021)
- Page 3 No part of this publication may be reproduced, copied, stored in a retrieval system, translated into any language or transmitted in any form or by any means, electronic, mechanical, photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc. (hereinafter referred to as “IBASE”).
- Page 4 Compliance The product described in this manual complies with all applicable European Union (CE) directives if it has a CE marking. For systems to remain CE compliant, only CE-compliant parts may be used. Maintaining CE compliance also requires proper cable and cabling techniques. This product has been tested and found to comply with the limits for a Class B device, pursuant to Part 15 of the FCC Rules.
-
Page 5: Important Safety Information
Important Safety Information Carefully read the following safety information before using this device. Setting up your system: • Put the device horizontally on a stable and solid surface. • Do not use this product near water or any heated source. •... - Page 6 Product Disassembly Do not try to repair, disassemble, or make modifications to the device. Doing so will void the warranty and may result in damage to the product or personal injury. CAUTION There is a danger of explosion if the lithium-ion battery is replaced with an incorrect battery. Replace only with the same or equivalent type recommended by the manufacturer.
-
Page 7: Warranty Policy
Warranty Policy • IBASE standard products: 24-month (2-year) warranty from the date of shipment. If the date of shipment cannot be ascertained, the product serial numbers can be used to determine the approximate shipping date. • -party parts: 12-month (1-year) warranty from delivery for 3 -party parts that are not manufactured by IBASE, such as CPU, CPU cooler, memory, storage devices, power adaptor, display panel and touch screen. -
Page 8: Chapter 1 General Information
Chapter 1 General Information The information provided in this chapter includes: 1.1 Introduction 1.2 Features 1.3 Packing List 1.4 Specifications 1.5 Product View 1.6 Dimensions... - Page 9 Artificial Intelligence education applications. The AIER102E model in the AIER1000 series uses one full-height PCIe capture card and two Full-HD SDI interface cameras to collect and analyze specific data for edge side system deployment.
-
Page 10: Packing List
1.3 Packing List 1 x AIER102E system 1 x Power cord 1 x Wall mount kit and screws 4 x Foot pads AIER102E 1 x Camera kit: (1) AIDA SDI interface Full HD cameras *2 (2) 12V power adaptor and power cables for camera *2 (3) 20M SDI cables *2 1 x AIER100C system 1 x Power cord... -
Page 11: Specifications
1.4 Specifications Product AIER102E AIER100C System Mainboard MI998AF-AI Operating System Microsoft Windows 10 (64-bit) 8th Gen Intel® Core™ i7-8700 Processor 3.20GHz, TDP ≤ 65W ® Chipset Intel Q370 PCH Memory 2x DDR4 SO-DIMM 2666/2400 MHz up to 32GB, default 2x 8GB ®... - Page 12 • 1x HDMI • 4x USB 3.0 • Rear Side I/O 2x RJ45 Gigabit LAN • 1x COM port RS232 • 1 x IEC 60320 (C14) AC Inlet Power Requirement AC 100V~240V Watchdog Timer 256 segments, 0, 1, 2…255 sec/min Watchdog Chassis Aluminum and SGCC, Gray &...
- Page 13 SDI Capture Card Video Input 4× SDI 1920×1080p@60/50fps in → 1920×1080p@60/50fps out Max. FPS 3G-SDI: 1920 x 1080p @60/50fps HD-SDI: Recording Video Resolution 1920 x 1080p @30/25/24fps, 1920 x 1080i @60/50fps, 1280 x 720p @60/50fps SD-SDI: 720 x 480i @60fps, 720 x 576i @50fps 3G-SDI Full HD Camera Image Sensor 1/3 inch Progressive CMOS...
-
Page 14: Product View
1.5 Product View Front View Rear View... - Page 15 1.6 Dimensions Unit: mm...
-
Page 16: Chapter 2 Hardware Installation
Chapter 2 Hardware Installation This section contains general information about: 2.1 Edge Side System Installation 2.2 Central Management Server Installation 2.3 Mounting Installation... - Page 17 2.1 Edge Side System Installation 1. Install AIER102E in each classroom.
- Page 18 Set up two cameras with default 20M SDI cable on the left and right sides of the front of the classroom. Make sure cameras can capture all students’ faces. Connect the cameras to the two ports as below. Be sure to connect port 1/2 and select 2 on the CHANNEL_NUMBER page.
- Page 19 If there is only one camera connected (whether on port1 or port2), select 1 on the CHANNEL_NUMBER page. Then you will see the corresponding image in the UI windows and another one will have a black screen. In other words, if one camera is connected to Port 1, the image will be shown at Channel 1, and Channel 2 will have a black screen and vice versa.
- Page 20 4. Use an HDMI 1.4 Type A cable to connect the AIER102E to your monitor. 5. Use a USB Type A connector for your keyboard & mouse. 6. After the above connections have been made, plug the power cord and start the system.
- Page 21 2.2 Central Management Server Installation 1. If there are many classrooms that need to be set up with the AIER102E system, prepare one AIER100C central management server at your office to simultaneously manage these AIER102E systems. 2. Connect all AIER102E and AIER100C to the ethernet. 3.
- Page 22 2.3 Mounting Installation Before mounting the system, ensure that you have enough space for the power cord and signal cable routing. Use the following methods for mounting your system: If you want to let the system stand as a desktop platform, turn your system upside down and attach the foot pads in the four corners as shown in the picture.
-
Page 23: Chapter 3 Software Setting
Chapter 3 Software Setting This section contains general information about: 3.1 Edge Side System UI Introduction 3.2 Central Management Server UI Introduction 3.1.1 User Interface Overview 3.2.1 User Interface Overview 3.1.2 Account Login 3.2.2 Account Login 3.1.3 Student Data Registration 3.2.3 Connect to Edge side system 3.1.4 Schedule Setting 3.2.4 Raw Data Export... - Page 24 Edge Side System UI Introduction 3.1.1 User Interface Overview...
- Page 25 Six emotion categories in student’s facial recognition Nine behavior detections of students in the classroom...
- Page 26 3.1.2 Account Login Please key in the default user name and password: admin...
- Page 27 To create a new user, click the “Setting” and then “Member” at the top left of the Setting page.
- Page 28 3.1.3 Student Data Registration Prepare the pictures of the students to register information in advance before using this UI. • Set up the Group information. "Group" means the group of students.
- Page 29 The methods of student registration. (1) Single Registration • Fill in the fields as shown in the picture. • Click Select photo to attach the picture file.
- Page 30 (2) Batch Registration • Setting up the filename of the pictures. The file name format: _Student ID_Student First Name-Last Name_Group ID_Birthday_Gender_ • Select photo to attach all files...
- Page 31 ➢ If you do not have the student picture ready, you can use the camera function to take a photo of the classroom. Double click the area to capture and take a picture. The picture will be automatically saved on the desktop of the computer.
-
Page 32: Schedule Setting
3.1.4 Schedule Setting (1) Click “Schedule” at the top of the screen and open the setting page. (2) Create “Course Name” (3) Chose the “Participative Group”... - Page 33 (4) Set up the course start time and end time.
- Page 34 (5) There are two repeat periods: Daily or Weekly.
- Page 35 3.1.5 Live Detection...
- Page 37 Press the F3 button on the keyboard and the system place the detected student in red frames.
- Page 38 ➢ Undetected mode 1. If a person does not want to be detected, do this setting. 2. Create a new group with the name “UNDETECTED”, for example.
- Page 39 3. Move the students who do not want to be detected into the “UNDETECTED” group.
- Page 40 4. In the course schedule calendar, do not select the “UNDETECTED” group in the student list.
- Page 41 5. During smart course detection, “UNDETECTED” students will not be included in the output AI data even if they are present in the classroom.
-
Page 42: System Information
3.1.6 System Information (1) Channel Number: The number of cameras connection (2) Video Source: Default is “Capture Card” (3) Class Name: The name of the classroom (4) Grade Name: The group of classrooms (5) Database Path: Specify the path where the database is stored (6) Record Path: Specify the path where the record is stored (7) Server IP: Used to connect to Server-side system (8) Max AI FPS: Maximum Frames Per Second... - Page 43 Click the "Reset" button to rearrange the value of each item. Follow the steps as below. (1) Click the “Reset” button at the lower right. (2) Click “Start”.
- Page 44 (3) Choose the number of camera connections and click “Next”. (4) The video source default is Capture Card. “File” is used only for testing purpose.
- Page 45 (5) Rename the classroom name. (6) Re-define the Grade of the classroom.
- Page 46 (7) Reset the database and record file paths.
- Page 47 (8) Set up the IP of server-side system. (9) Set up the frames per second. (When the edge side needs to connect to the server side) Maximum Frames per Second is 5.
- Page 48 3.1.7 Report Export According to the Record Path in the System page, you can find the detection data via CSV file. The file is named by the course name.
- Page 49 Introduction to the CSV file format AI code comparison table...
- Page 50 3.1.8 Video recording All MP4 video files are saved in the specified path.
- Page 51 3.1.9 Activity Controls How to find your activity controls? Open the AppData file. Choose the date file you want. You'll find activity logs in the file.
- Page 52 Central Management Server UI Introduction 3.2.1 User Interface Overview...
-
Page 53: Account Login
3.2.2 Account Login Please key in the default value for the user name and password: admin... - Page 54 3.2.3 Connect to Edge side system Please fill in the Server IP address on this page of each edge side system. When the connection between edge side and server side is successful, a green light will be displayed. When the connection fails, a red light will be displayed.
- Page 55 3.2.4 Raw Data Export Click the export button. There are four conditions to filter. (1) Start Date (2) Report Period (3) Rule (Course, Student Group, Student ID) (4) Data Format Click “Export” and the CSV file will be saved in the C drive of the computer.
- Page 56 Introduction to the CSV file format AI code comparison table...
