ConMed Sabre 2400 Operators & Service Manual page 72

R
Ref. Des.
ASSEMBLY: Display Board (A7), 61-4913
C1,2
I1,3,5,7,8,10,16,17,19
I2,6
I4
I9,18
I11,14
I12,15
I13
P1,2
R1,2,5,6
R3,4
RN1-RN6, RN9-RN11
RN7,8
U1-U12
N/A
N/A
ASSEMBLY: Footswitch Harness (A5W1)
A1P8
A5J1
A5J2
E1,2
N/A
N/A
N/A
N/A
N/A
N/A
N/A
ASSEMBLY: Miscellaneous
N/A
N/A
N/A
N/A
N/A
N/A
4-28
Part Number Description
62-0267-003 CAP , 0.33uF 50V CERAMIC
62-1361-001 DISPLAY, LED 7 SEG, CA, RED
62-1360-002 LAMP , LED LIGHTBAR, YEL
62-1643-001 LAMP , INCAND, 14V , YEL
62-1643-002 LAMP , INCAND, 14V , BLU
62-1360-001 LAMP , LED LIGHTBAR, RED
62-1360-003 LAMP , LED LIGHTBAR, GRN
62-3462-001 DISPLAY, LED BARGRAPH 10X, GRN
62-4921-001 HARNESS, RIBBON, 50 COND, PWB/DIL
62-0364-046 RES, 200, 1/4W , 5%, CC
62-0364-056 RES, 510, 1/4W , 5%,CC
62-3463-006 RES. NET, 8X390 16 PIN DIP
62-2861-002 RES. NET, 5X200, 6 PIN SIP
62-1374-002 IC,DRIVER, ULN2004
62-4912-001 PWB, DISPLAY A7, Sabre 2400 LED
62-2772-001 CONN, SOCKET STRIP , 10 PIN
62-1389-005 CONNECTOR, PLUG, 6 PIN
62-0279-001 CONNECTOR, 4 PIN
62-0279-002 CONNECTOR, 3 PIN
62-0314-002 GROUND LUG, #4
62-0260-001 CABLE TIE, 3.5''
62-1388-001 TERMINAL, CRIMP
62-0339-004 TUBING, PVC 105/0
62-0620-003 TUBING, 3/32'' HEATSHRINK
62-0431-001 WIRE, 22 AWG BUS
62-4427-002 WIRE, #24 TWISTED BLK/WHT
62-4427-007 WIRE, #24 TWISTED BLK/YEL/BLU
60-5601-002 MANUAL
62-4783-001 CARTON, Sabre 2400 SHIPPING
62-4784-001 INSTAPAK, Sabre 2400 TOP
62-4787-001 INSTAPAK, Sabre 2400 BOTTOM
62-4287-004 SCREW , 8-32X1/2, BHPH
62-0343-002 NUT, KEPS, 6-32
