Connection Tab - Casio DT-X8 Series Software Manual

Connection Tab

Figure 3-21
Use LAN (no autodial)
Check the checkbox to connect the terminal in LAN mode.
Autodial name
Choose an autodial name in the pull-down menu when communication is made without the use of
LAN.
Access the Internet using a proxy server
Check the checkbox when a proxy server is used for accessing to Internet. In this case, specify the
appropriate items and value in the fields below as needed.
- Address
- Port
- Bypass proxy server for local address
150
