Local Configuration
3.7 Network Settings – LAN
The LAN interface must be enabled when using EtherNet/IP or Modbus TCP applications and
when using the Netbiter Remote Access service.
These settings can also be made in Argos. See the Argos documentation.
Fig. 31 LAN settings
To avoid potential address conflicts when setting a static IP address and netmask for the LAN
port, use only the address spaces that are reserved for private networks:
• 10.0.0.1 – 10.255.255.254
• 172.16.0.1 – 172.31.255.254
• 192.168.0.1 – 192.168.255.254
Click on Save settings when finished.
A change in the Network settings needs a reboot of the Netbiter and is indicated by a flag icon
near the System label in the menu. For more information, refer to
3.8

Modem Settings (EC320/EC350/EC360)

Modem settings and information about the mobile connection.
These settings can also be made in Argos. A SIM card with SMS capability is required. See the
Argos documentation.
Netbiter EC300 Series User Manual
Do not connect the LAN and WAN ports to the same logical network.
19 (28)
System, p. 22
SCM-1202-012 2.3 en-US
