Appendix A: EtherNet/IP Implementation
A

EtherNet/IP Implementation

See also the Argos documentation on how to configure EtherNet/IP.
A.1

Client

Connection Type
UCMM (Class 1 and 3 connection not supported)
Adapter Timeout
1000 ms
Services
The following services are implemented:
Code
0x0E
0x10
0x4C
0x4D
Read_Tag_Service and Write_Tag_Service using symbolic segment addressing is only supported by some
PLCs. Please refer to the PLC vendor's documentation for more information.
A.2

Adapter

A.2.1 Identity Object (0x01)
Class Attributes
No attributes are implemented.
Instances
Instance 1 is implemented with the following attributes:
ID
1
2
3
4
5
6
7
Services
The following services are implemented:
Code
0x01
0x0E
Netbiter EC300 Series User Manual
Service Name Addressing
Get_Attribute_Single Class, Instance,
Attribute
Set_Attribute_Single Class, Instance,
Attribute
Read_Tag_Service Symbolic Segment
Addressing
Write_Tag_Service
Access Name
Get
Vendor ID
Get Device Type
Get
Product Code
Get Revision
Get Status
Get Serial Number
Get Product Name
Instance
Class
No Yes
No Yes
Note
Can be used to access Controller Tags.
Vendor specific service code (see note below).
Value
90
100
85
1
1
...
Netbiter
Service Name
Get_Attribute_All
Get_Attribute_Single
23 (28)
