Setup Antennas (Roll Antenna)*
*VB20SL3 triple antenna units only
SEPARATION
LEVEL
ROLL OFFSET
BACK
https://racelogic.support//01VBOX_data_loggers/VBOX_II_Range/VBOX_II_User_Guide/01_-_VBOX_II_Front_Panel
Press'■' and then use the '◄' and '►' buttons to change
the antenna separation. Then press '■' to confirm.
Range is 0.5 – 5.0 m in 0.1 m increments
Press '■' and then use the '◄' and '►' buttons to enable
or disable the LEVEL option. With the LEVEL set to YES
the RTK lock is more resilient.
But maximum ROLL or PITCH in this mode should be
10 degrees.
Press '■' to enter the Roll offset sub menu. Within this
sub menu a Roll offset can be calculated and applied or
cleared.
Press '■' to go back to the Main menu.
6
