Dynamic Mode; Dgps Mode; Kalman Filter; Factory Reset - Racelogic VBOX II Manual

GPS Menu

DYNAMIC MODE

DGPS MODE

KALMAN FILTER

BACK
*Note: These accuracies are only achievable in conjunction with a DGPS base station

Factory Reset

To perform a factory reset on the unit, if for example the unit is not functioning correctly, press and hold the '■'
and '►' buttons whilst power is supplied to the VBOX II. The front panel screen will display an 'updating
https://racelogic.support//01VBOX_data_loggers/VBOX_II_Range/VBOX_II_User_Guide/01_-_VBOX_II_Front_Panel
Press '■' and then the '◄' and '►' buttons to select the
required dynamics.
HIGH DYNAMICS - Essential for brake testing and lane
changing manoeuvres.
NORMAL - Select this for standard testing – speed,
distance, etc.
LOW DYNAMICS - Select this for route mapping and
similar tests where the level of dynamic response is not
important.
Press'■' and then the '◄' and '►' buttons to select the
DGPS settings.
OFF – No DGPS applied – standard position accuracy
3 m CEP
WAAS – position accuracy 1.8 m CEP
40CM – position accuracy 40CM*
20CM – position accuracy 20CM*
Press '■' and then the '◄' and '►' buttons to set
Kalman filter options.
POSITION LEVEL – Smoothes the positional data
VELOCITY LEVEL – Smoothes the velocity data
Press'■' to return to the GPS menu
