HINT600VH / HINT600H
Intensifier H® Series Color Miniature Board Camera
DIMENSIONS
2.5"
CONFIGURATION
[HINT600VH]
[HINT600H]
① ① ① ①
D C 12V
⑤ ⑤ ⑤ ⑤
O SD Joy-Stick
1.1"
2.1"
3.5"
2.1"
2.5"
2.5"
⑥ ⑥ ⑥ ⑥
③ ③ ③ ③ ④ ④ ④ ④
⑤ ⑤ ⑤ ⑤
① ① ① ① ② ② ② ②
③ ③ ③ ③ ④ ④ ④ ④
⑤ ⑤ ⑤ ⑤
① ① ① ① ② ② ② ②
/
② ② ② ②
G ND
/
③ ③ ③ ③
V IDEO
④ ④ ④ ④
N /C
⑥ ⑥ ⑥ ⑥
I RIS Jack for DC Lens
[HINT600VH]
1.4"
[HINT600H]
1.4"
OSD MENU TREE
PRESET MODE
• INDOOR • OUTDOOR • LOW LIGHT • LOBBY • HALLWAY • ELEVATOR
MAIN SETUP***
EXIT
• SAVE
• RESTORE • INITIAL
MAIN SETUP***
EXPOSURE
• ALC
• AGC
• INTENSIFY
DAY / NIGHT
• DAY
• NIGHT
WHITE BAL
• ATW
• PUSH
MONITOR
• GAMMA
• CHROMA
• BACKLIGHT
•CONTRAST • POSI/NEGA
• BLC • HLC
• WDR
SPECO DNR
• LOW / MIDDLE / HIGH / OFF
MOTION
SYSTEM
• CAM ID • ID DISP • SYNC
• CAM TITLE
200 New Highway, Amityville, NY 11701
800-645-5516 / www.specotech.com
*Accessory *
1 mounting screw
1.6"
• EXT.
• AUTO
• MANUAL
• SHARPNESS • SHADING
• PED.LV
•H-MIRROR
• DEFOG
•SPECIAL
• LANGUAGE
1.4"
•PRIVACY
