Observe the following guidelines when using a portable MAP Gateway:
• Do not use the RJ-12 cable to support the weight of the MAP Gateway. Use the lanyard to
support it.
• Keep the MAP Gateway in the protective shell with which it ships. To insert the MAP Gateway
into the shell, stretch the shell edges and slide the MAP Gateway unit into place (Figure 1). This
shell protects the unit from drops up to 1.22 m (4 ft).
• The MAP Gateway has not been designed for prolonged outdoor use. Leaving it in outdoor
environments (such as inside rooftop units) may result in damage.
• Objects (including ductwork, cabinets, doors, and glass) can impede the wireless signal.
Minimize the number of objects between the connected computer or mobile device and the
MAP Gateway. Use line of sight, if possible.
• Metal objects (such as cabinet doors, enclosures, and pipes) and concrete objects (such
as pillars, walls, and ceilings) may limit Wi-Fi service. To accommodate potential structural
obstacles on site, the MAP Gateway can be mounted flat or on the side.
Risk of Property Damage.
Do not use the RJ-12 cable or any other field bus cable or electrical cable to support the weight of the
MAP Gateway. Hanging the MAP Gateway from anything other than the supplied lanyard may result in
damage to the product or peripheral equipment.
Risque de dégâts matériels.
Ne pas utiliser le câble RJ-12 ou tout autre câble de bus de terrain ou câble électrique pour soutenir le
poids de l'MAP Gateway. La suspension de l'MAP Gateway à tout autre élément que la longe fournie
risque d'endommager le produit ou les équipements périphériques.
8
 CAUTION
 CAUTION
Mobile Access Portal Gateway Installation Guide
