Summary of Contents for PR Lighting XPar 1514 ZOOM
- Page 1 XPar 1514 ZOOM PR-8210 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD.
- Page 2 Any future technical change in the user manual won’t be with any further notice. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty.
-
Page 3: Safety And Warnings
1. SAFETY AND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. User Electrical Protective High Warning Flames Goggles Manual shock Gloves Temperature ●... - Page 4 supplied through the safety cord holes for safety support. ●Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from power mains. ●Under normal temperature, the temperature of the housing will be 55℃; after being stable, the unit’s ℃...
-
Page 5: Installation
3. APPEARANCE Barn door Body 4. INSTALLATION Clamp Safety cord Warming: For safety, please run the safety cord through the arm and 。 ensure it is tightened ●RIGGING Take 1 clamp and 1 safety cord out from the package and tighten the clamp with the arm, and then mount the whole unit on the truss, tighten the clamp’s retainers to keep the unit stable. - Page 6 ●INSTALLATION OF BARN DOOR If barn door selected, its installation is illustrated in the diagram below: Loosen the screw in the shape of a butterfly in the front part of the unit, turn the clipping component in the shape of 7 by a little amount, then place the barn door.
- Page 7 ● DMX CONTROL CONNECTION: Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the projector) or 5 pin XLR plugs and sockets.
-
Page 8: Setup And Configuration
DMX TERMINATOR CONNECTION Connect a 120 (OHM) resistor across pins 2 and 3 in an XLR plug and insert into the DMX out socket on the last unit in the chain. PIN 2 PIN 3 5. SETUP AND CONFIGURATION ● FRONT PANEL OPERATION To browse through or modify the projector’s functions, press key ENTER for more than 3 seconds to unlock the control panel and enter the menus. - Page 9 be set accordingly After Powered on, the group will run in Master/Slave Mode Slave Slave Master DMX TEMINATOR POWER POWER IN POWER OUT POWER IN POWER OUT DMX CONTROLLER DMX IN DMX OUT DMX IN DMX OUT 9/20...
-
Page 10: Operation Menu
6. OPERATION MENU 1st level menu 2nd level menu 3rd level menu 4th level menu DMX 地址 DMX Address 001 - 501 Reset Zoom Reset Config Setup Basic DMX Channel Mode Standard Extended HSIC Slave MasterSlave Default：Slave Master ZOOM Position 000 - 255 For preset memory Color Offset... - Page 11 Preset Memory （PR01~PR16） Dimmer 000 - 255 Strob 000 - 255 000 - 255 Green 000 - 255 User Progra Edit （ET01~ET16） Blue 000 - 255 White 000 - 255 Zoom 000 - 255 000 – 200 (0- 20S) Keep Time Note: In one DMX chain, only one unit can be made as the master.
-
Page 12: Dmx Protocol
7. DMX PROTOCOL Basic Standard Extended HSI HSIC Function DMX Value Description mode mode mode 000-255 8bit hue Hue Fine 000-255 16bit hue Saturation 000-255 Linear adjustment from 000-255 dark to bright Brightness Brightness adjustment in 0-255 16bit Brightness Fine 000-007 Strobe Strobe speed from slow to... - Page 13 001-015 Preset memory 1 016-031 Preset memory 2 032-047 Preset memory 3 048-063 Preset memory 4 064-079 Preset memory 5 080-095 Preset memory 6 096-111 Preset memory 7 112-127 Preset memory 8 128-143 Preset memory 9 144-159 Preset memory 10 160-175 Preset memory 11 176-191...
- Page 14 176-191 Speed 12 192-207 Speed 13 208-223 Speed 14 224-239 Speed 15 240-255 Speed 16，Slowest 0-188 Reserved Function 180-189 Zoon Reset 190-255 Reserved Note: DMX channel priority: Preset memory> user memory >Macros>CT>RGBW dimming While higher priority channels are in use, lower priority channels don’t work. 14/20...
-
Page 15: Technical Data
TECHNICAL DATA INPUT VOLTAGES ，50/60Hz 100V~240V AC RATED POWER 220W@220V LIGHT SOURCE SPECIFICATIONS 14pcs, Osram ,15W RGBWB,4 in 1, SMT LED Power Consumption 15 W ,14pcs Manufacturers Rated Lamp Life 50000hours Color temperature: 2700K~10000K，linear adjustment COLORS R/G/B/W, Macros, unlimited color mixings DIMMER Linear Dimmer from 0-100% STROBE... -
Page 16: Operation Temperature
OPERATION TEMPERATURE 40 ℃ Maximum ambient temperature: SIZES: LIGHT OUTPUT: 36.0°Lux 6.0°Lux 23334 5834 2593 1458 DISTANCE (m) 12.5 6.0°DIAMETER (m) 0.52 1.05 3.14 1.57 2.09 2.62 Note： The luminous flux is measured when the hotspot is 1m in diameter and the bean angle 69 degrees. 16/20... -
Page 17: Circuit Diagram And Pcb Connections
9. CIRCUIT DIAGRAM AND PCB CONNECTIONS ● CIRCUIT DIAGRAM 17/20... - Page 18 ●PCB CONNECTIONS Master Board 序号 名称 Temperature Empty PWM dimming MOTOR Power Empty Empty DMX signal Empty Diver board Name LED Dimming Power Temperature 18/20...
-
Page 19: Component Order Codes
10. COMPONENT ORDER CODES Name Code No. Remarks 6030040235A STEPPING MOTOR 6192010188 POWER SWITCH 6230000001 MASTER BOARD OF PR-8210 6230000002 LAMP BOARD OF PR-8210 6290000005 MIXING ROD OF PR-6200 19/20... - Page 20 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 6320000001...
