- Page 1 XR330 Framing PR-2357 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-lighting.com...
- Page 2 INDEX SAFE USAGE OF THE PROJECTOR INSTALLING THE PROJECTOR FITTING THE LAMP POWER SUPPLY – MAINS CONTROL CONNECTIONS DMX TERMINATOR SETUP OPTIONS-PROJECTOR CONFIGURATION TO SET THE DMX START ADDRESS STAND-ALONE MODE MASTER/SLAVE MODE OPERATION MENU ERROR MESSAGES REPLACING GOBOS DMX PROTOCOL LED INDICATION MAINTENANCE LUBRICATION...
- Page 3 FE USAGE E OF THE E PROJEC CTOR When unpac cking and befor re disposing of the carton chec ck there is no tr ransportation da amage before u using the project tor. Should ther be any dama age caused by tr ransportation, co onsult your dea aler and do not u...
-
Page 4: Install The Projector
INSTALL THE PROJECTOR Warning Please run the safety cord Clamp through two holes for safety. Safety Cord Handle Digital Control Panel Take 2 clamps and the safety cord out from the package and mount 2 clamps on the underside of fixture with 2 retainers attached to each clamp. -
Page 5: Power Supply-Mains
POWER SUPPLY-MAINS Connect the power cord as follows: L (live) =brown E (earth) =yellow/green N (neutral) =blue Before connection with mains power, make sure that the voltage and frequency marked on the rating plate of the projector match what are supplied. It is recommended that each projector be supplied separately so that they may be individually switched on and off. IMPORTANT It is essential that each projector is correctly earthed(yellow/green twin wire) and the electrical installation conforms to all relevant standards. -
Page 6: Dmx Terminator
DMX TERMINATOR In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents electrical noise from disturbing and corrupting the DMX control signals. The DMX terminator is simply an XLR connector with a 120Ω (ohm) resistor connected across pins 2 and 3, which is then plugged into the output socket on the last projector in the chain. -
Page 7: Standalone Mode
STAND-ALONE MODE Operate the projector without connecting with a controller, enable the master mode through the operation panel, the projector will run in Stand-Alone mode automatically. DMX address can be set at any number within 512. MASTER/SLAVE MODE Many projectors can run synchronously in the Master/Slave mode by linking them with each other. First, connect the first fixture’s DMX output to the second fixture’s DMX input using XLR-XLR control cable and then connect the second fixture’s DMX output to the third fixture’s DMX input, and so on until all projector are connected in this way. -
Page 8: Operation Menu
OPERATION MENU First Menu Secondary Menu Third Menu Fourth Menu DMX Address=XXX DMX Address Reset Are You Sure Standard DMX Mode Extended Short By Control Channel Lamp Control By Power On By DMX Present Config Settings When DMX is Lost Normal time out Loss of DMX When DMX is Lost... - Page 9 Zoom Invert Zoom Invert Zoom Invert CYM Invert CYM Invert CYM Invert Defaults Defaults Defaults Restore Defaults Display On Always Display Mode Display Off After Delay Display Invert Display Invert Display Invert Disp Dim Level Disp Dim Level Disp Dim Level Disp Dim Level Display Options Disp Dim Level...
- Page 10 Driver Board 1= Driver Board 1 X.X.X Driver Board 2= Driver Board 2 X.X.X Driver Board 3= Driver Board 3 X.X.X Driver Board 4 Driver Board 4 X.X.X Pan and Tilt= Pan and Tilt X.X.X DMX Channel View DMX Values 1=XXX Electronic SN= Electronic SN...
- Page 11 Preset Memory 3 User’s Memory 1 User’s Memory 2 Operation Mode= Preset Memory 1 Slave Mode Preset Memory 2 Preset Memory 3 Operation Mode= Standalone Mode Shutters Shutters XXX Dimmer Dimmer XXX Slow Dimmer Slow Dimmer XXX CYM Macro CYM Macro XXX Cyan Cyan XXX Yellow...
- Page 12 Frost Frost XXX Focus Focus XXX Zoom Zoom XXX Pan XXX Pan Fine Pan Fine XXX Tilt Tilt XXX Tilt Fine Tilt Fine XXX Motors’ Speeds XXX Motors’ Speeds （000~255） Delay XX s Delay （0.25s~100min） Shift to scene Shift to next scene XXX（1~200）...
-
Page 13: Error Messages
UP/DOWN/ENTER to execute the function） Clear single scene 1？ （Press buttons 2,3.4,ie Single Scene 1 Clear Single Scene buttons cleared UP/DOWN/ENTER to execute the function） ERROR MESSAGES In the course of launch, Projector examines automatically whether there are errors and if there are, it will display information as follows: Sensor Err S1-M1 Color wheel (1# drive board motor 1) error... -
Page 14: Replacing Gobos
REPLACING GOBOS Replacement of rotating gobos: rotating gobo wheel disconnect from power, loosen the four fastfit screws of the side cover rotator like figure 1, pull out the rotators by finger as figure 2. figure 2 rotator garter spring gobo figure 1 14/24... -
Page 15: Dmx Protocol
DMX PROTOCOL SHORT STANDARD EXTENDED FUNCTION DESCRIPTION MODE MODE MODE Close 000-010 Open 011-025 Strobe speed from slow to fast 026-225 Strobe 226-239 Macro 1 240-241 Macro 2 242-246 Macro 3 247-255 Open 000-003 Close Dimmer 004-255 Linear dimming （0-100%） 0-255 Dimmer Fine Dimmer in 16 bit... - Page 16 Iris 000-255 From Big to Small In size Iris Fine 000-255 Iris in 16 Bit 000-010 White Iris Effect 1 011-072 Iris Effect 2 073-136 137-198 Iris Effect 3 Iris Macro 199-214 Iris Effect 4 215-222 Iris Effect 5 223-230 Iris Effect 6 231-255 Fully Open...
- Page 17 Linear light spot from big to small(blade Framing Blade2 000-255 2/right) (right) Light spot 16 bit precision(blade 2/right) 000-255 Linear light spot from big to small(blade Framing Blade3 000-255 3/left) (Left) Light spot 16 bit precision(blade 3/left) 000-255 Linear light spot from big to small(blade Framing Blade3 000-255 3/right)
-
Page 18: Led Indication
LED INDICATION DMX signal OK Green No DMX signal Flash DMX signal error Yellow Setting the panel Blue Power Red/Green Slave mode or Self-Test Mode MAINTENANCE If the projector’s lens becomes damaged or broken it should be replaced. If the lamp becomes damaged or deformed in any way it must be replaced. -
Page 19: Technical Data
TECHNICAL DATA VOLTAGES: 100V~240V AC，50/60Hz POWER CONSUMPTION: 450W@220V LAMP: SIRIUS HRI 330W XL OSRAM Colour Temperature 7500K Manufacturers Rated Lamp Life 1500 hours COLORS: CMY linear mixing system with macros 1 color wheel: 14colors+ open Rainbow effect with bi-directional and variable speeds Stepping/Linear color changing FRAMING MODULE: 1 Framing module: 4 framing blades... - Page 20 0-100% linearly adjustable/ Double shutter blades, 0.3~25 F.P.S HEAD MOVEMENT: Pan 540º, Tilt 270º with auto position correction BEAM ANGLE: 3.8°-35°, Linear Adjustment CONTROL: DMX512, 3 pins and 5 pins interfaces 28channels in short mode, 34channels in standard mode and 48channels in extended mode Self-test mode OTHER FUNCTIONS: Adjustable Pan &...
- Page 21 LIGHT OUTPUT: 35° Lux 2071 3.8°Lux 9949 39795 17687 4422 159181 6367 3.8° 射距 (m) 光斑直径 (m) 1.99 0.33 1.65 0.66 0.99 1.32 光斑直径 (m) 2.86 14.32 17.18 5.73 8.59 11.45 21/24...
- Page 22 Circuit Diagram 22/24...
- Page 23 omponent Order Code NAME PART NO. QUANTITY REMARK 030040233 PAN MOTOR TILT MOTOR 030040233 030040213A DIMMER/STROBE MOTORS CYM MOTOR 030040228A 030040231A ROTATING GOBO WHEEL MOTOR GOBO ROTATION MOTOR 030040219 030040221A COLOR WHEEL MOTOR 030040081A IRIS MOTOR FRAMING MODULE ROTATION 030040155 MOTOR 030040236 FRAMING BLADE MOTOR...
- Page 24 PR LIGHTING LTD. 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N: 320020286 Version: 20150410 (Preliminary） 24/24...
