  • Page 2 INDEX SAFE USAGE OF THE PROJECTOR INSTALLING THE PROJECTOR POWER SUPPLY – MAINS CONTROL CONNECTIONS DMX TERMINATOR SETUP OPTIONS-PROJECTOR CONFIGURATION TO SET THE DMX START ADDRESS OPERATION MENU DMX PROTOCOL LED INDICATION MAINTENANCE KEEPING THE PROJECTOR CLEAN TROUBLESHOOTING TECHNICAL DATA ELECTRICAL DIAGRAM COMPONENT ORDER CODES Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change without...

  • Page 7: Operation Menu

    OPERATION MENU 1st LEVEL 2nd LEVEL 3rd LEVEL 4th LEVEL 5th LEVEL 6th LEVEL PR LIGHTING PR LIGHTING DMX Address DMX Address PR LIGHTING PR LIGHTING Reset Reset Are You Sure PR LIGHTING DMX Mode Standard 16 PR LIGHTING PR LIGHTING...
  • Page 8 PR LIGHTING Display Invert PR LIGHTING PR LIGHTING Display Options PR LIGHTING Display Invert Display Invert PR LIGHTING PR LIGHTING Disp Dim Level Display Dimming PR LIGHTING PR LIGHTING Display Contrast Display Contrast PR LIGHTING PR LIGHTING LED Hours =...
  • Page 9 PR LIGHTING Operation Mode = DMX Operation PR LIGHTING Select Memory User Memory 1 PR LIGHTING Select Memory User Memory 2 PR LIGHTING PR LIGHTING Operation Mode = Select Memory Master Mode Preset Memory 1 PR LIGHTING Select Memory Preset Memory 2...
  • Page 10 PR LIGHTING PR LIGHTING Pan Coarse Pan Coarse PR LIGHTING PR LIGHTING PR LIGHTING PR LIGHTING Pan Fine User Memory Scene Pan Fine PR LIGHTING PR LIGHTING Tilt Coarse Tilt Coarse PR LIGHTING PR LIGHTING Tilt Fine Tilt Fine PR LIG TING...
  • Page 11 PR LIGHTING PR LIGHTING Delay Delay X.XX Seconds PR LIGHTING PR LIGHTING Link To Step Link To Step PR LIGHTING PR LIGHTING Dimmer Dimmer PR LIGHTING PR LIGHTING Color Temp. Color Temp. PR LIGHTING PR LIGHTING RGB Macros RGB Macros...

  • Page 12: Dmx Protocol

    DMX PROTOCOL Short Standard Extended FUNCTION DESCRIPTION mode mode mode Dimmer 000-255 Dimming from dark to light Dimmer 16 Bit 000-255 Dimmer in 16 Bit precision Colour Temperature 000-255 Colour temperature adjustment The projector functions and contr 000-016 by RGB channels 017-024 White (Colour Temperature 100 0K) 025-032...

  • Page 13: Led Indication

    LED INDICATION DMX signal OK Green No DMX signal Flash DMX signal error Yellow Setting the panel Blue Power Slave mode or Running self test mode Red/Green Green Master mode MAINTENANCE To prolong the life of the projector, some maintenance work has to be done to ensure the LED opt al system in good condition.

  • Page 14: Technical Data

    TECHNICAL DATA VOLTAGES: 100V/120V/200V/220V /230V/240V AC, 50/60Hz POWER CONSUMPTION: 480W@220V LED: Type OSRAM Diamond Dragon Power consumption Amount 90 （30R＋30G＋30B） Manufacturers Rated LED Life 50000 Hours COLOURS: RGB colour mixing COLOUR TEMPERATURE CORRECTION: Linearly colour temperature correction DIMMER: 0-100% linearly adjustable STROBE: 1~25 F.P.S HEAD MOVEMENT:...
  • Page 16 +24V A-IN1 A-IN2...

  • Page 17: Component Order Codes

    COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK PAN ROTATION MOTOR 030040052 23HS0015L TILT ROTATION MOTOR FAN IN BASE 030060060 DC24V, 0.14A FAN IN LAMP HEAD 030060061 DC24V, 0.22A 070070006 LENS 150020201 150020202 Green 150020204 Dark blue POWER STWITCH 190010104 AC250V,10A 192010130 DC24V/2A...
  • Page 18 PR LIGHTING LTD. PR New Hi-tech Science Park, 1582 Xingye Avenue Nancun Panyu, Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N: 320050005 Last Revision: 20090324 18/18...
