D E S C R I P T I O N
Echotel Models 344 and 345 are full-featured, ultrasonic
non-contact transmitters that provide continuous mea-
surement for liquid level, volume, or open channel flow
applications. These versatile transmitters utilize the
latest in microprocessor-based electronics along with
powerful non-contact ultrasonic transducers, to provide
level measurement that is not affected by changes in
specific gravity, viscosity, or conductivity.
Model 344 and 345 are remote mounted transmitters
that feature a front panel keypad, and a large
16-character alphanumeric display of all parameters.
These transmitters are paired up with Kynar
316 stainless steel EchoMaster™ Ultrasonic Transducers
that have extensive agency approvals for hazardous
area locations.
F E A T U R E S
•
Front panel keypad for ease of programming – no
need to open enclosure after wiring
•
4–20 mA isolated (1,000 Ω load) and RS-232 outputs
•
Four 10 amp SPDT relays allow for simple alarm
configurations to complex pump control including
lead/lag alternation of pumps
•
Password code prevents unauthorized tampering of
calibration parameters
•
16-character alphanumeric display of all parameters.
•
Complete self-diagnostics assures unit is operating
properly by checking all relays, outputs, and system
functionality
•
Temperature compensation integral to all ultrasonic
transducers
•
False target buffering eliminates signal interference
from fixed obstructions in vessel
Echotel
®
Models 344/345
Ultrasonic Non-Contact
Transmitters for Level,
Volume, or Open Channel Flow
®
and
A P P L I C A T I O N S
•
Water and wastewater
•
Slurries
•
Viscous fluids
•
Fuel oils
•
Acids
•
Caustics
Advertisement
Related Manuals for Magnetrol Echotel 344
Summary of Contents for Magnetrol Echotel 344
- Page 1 Echotel ® Models 344/345 Ultrasonic Non-Contact Transmitters for Level, Volume, or Open Channel Flow D E S C R I P T I O N Echotel Models 344 and 345 are full-featured, ultrasonic non-contact transmitters that provide continuous mea- surement for liquid level, volume, or open channel flow applications.
- Page 2 T E C H N O L O G Y Model 344 and 345 systems consists of three main com- returned to the transducer. The piezoelectric crystal then ponents: an ultrasonic transducer, a transmitter, and an converts the returned echo into an electrical signal which interconnecting cable package.
- Page 3 T Y P I C A L M O U N T I N G C O N F I G U R A T I O N S Figure 2 shows a typical transducer mounting on a brack- of the vessel. This helps to keep the 12 degree ultrasonic et for open channel flow measurement.
-
Page 4: Specifications
F A L S E T A R G E T D E T E C T I O N When it is impossible to mount the transducer far enough away from obstructions in the vessel a unique false target detection feature can be used. This target detection mode programs the transducer to search for, and display, the distance of the target nearest the trans- ducer. - Page 5 T R A N S D U C E R S P E C I F I C A T I O N S Model 384 Model 385 Transducer frequency 38 kHz 50 kHz Maximum range 35 feet (10.7 meters) 25 feet (7.6 meters) Maximum span 33.5 feet (10.2 meters)
- Page 6 M E A S U R E M E N T R A N G E C A L C U L A T I O N S Ultrasonic non-contact devices are typically rated for a Sensor alignment maximum range in ideal conditions. Experience has shown that maximum range must be reduced for certain factors.
- Page 7 M E A S U R E M E N T R A N G E C A L C U L A T I O N S Performance Operating Parameter Condition Application Multiplier Smooth, glass-like surface SURFACE AGITATION: Surface agitation or waves can degrade the Slight agitation, choppiness performance.
- Page 8 D I M E N S I O N A L S P E C I F I C A T I O N S I N C H E S ( M M ) M O D E L 3 4 4 & 3 4 5 T R A N S M I T T E R S 9.50 (241) 6.75...
- Page 9 D I M E N S I O N A L S P E C I F I C A T I O N S I N C H E S ( M M ) 1" NPT M O D E L 3 8 4 T R A N S D U C E R S Process Connection 10.00"...
- Page 10 T R A N S M I T T E R M O D E L N U M B E R Models available for quick shipment, usually within one week after factory receipt of a purchase order, through the Expedite Ship Plan (ESP) BASIC MODEL Ultrasonic non-contact transmitter, used with Model 384 transducer Ultrasonic non-contact transmitter, used with Model 385 transducer...
- Page 11 M O D E L 3 8 5 k H z T R A N S D U C E R M O D E L N U M B E R PROCESS CONNECTION ⁄ " NPT, not available with transducer housing code 1 or Y 2"...
-
Page 12: Warranty
For additional information, see Instruction Manual 51-629. 5300 Belmont Road • Downers Grove, Illinois 60515-4499 • 630-969-4000 • Fax 630-969-9489 • www.magnetrol.com 145 Jardin Drive, Units 1 & 2 • Concord, Ontario Canada L4K 1X7 • 905-738-9600 • Fax 905-738-1306 Heikenstraat 6 •...
