Technical data ems75sz

11.1

Dimensional drawings:

11.2

Controller relays:

Relay IEC 60730 rating @ 100-120VAC and 220-240VAC 50/60Hz
Compressor 10 (10) A, p.f. 0.6
Light 4 (4) A, p.f. 0.6
Evaporator fan 6 (6) A, p.f. 0.6
Auxiliary* 6 (6) A, p.f. 0.6
11.3

Temperature sensors:

Sensor Input range (
-10
Appliance sensor
o
C)
o o
C to 23.3 C
82 of 86
27 February 2014
*relay used for defrost functionality
o
Input range ( F)
o o
14 F to 74 F
