(Figure 20)
4 - Press the operating pedal (F) (Fig. 20) and keep it depres-
sed until the trimming has completely finished.
If you release the pedal before completing the trimming ope-
ration, the trimmer arm will automatically return to its star-
ting position and the clamp will release the board it has been
holding in position.
The machine is equipped with a detachable guide (B) (Fig. 20)
to support long boards.
G
The frame has been designed with non-slip ma-
terial with properties that protect the board
and mean that this area is always clean and
F
free of dust or fine shavings, so avoiding marks
or scratches being made on the boards

6.3 TIPS FOR A GOOD FINISH

To obtain a good finish, several useful tips should be taken
into account that can be summarized in three groups:
Boards to work on:
• It is advisable to use good quality, high density boards.
• Cuts must be clean, with no rough edges.
• The boards must be as flat as possible and unwarped.
A tolerance of ± 0.1 mm per metre is recommended.
• Boards must be clean
• The cut must be made at 90º to the board thickness and
length.
Test board:
It is highly recommended to perform a test before beginning
the trimming of an entire manufacturing series. This way, if
the results of the test are unsatisfactory, small corrections
can be made in the settings without possible losses in the
series.
7.

MAINTENANCE REQUIREMENTS

SPARE PARTS AND MAINTENANCE
CAUTION
Before performing cleaning, maintenance or adjustment
operations and/or replacing any part, it is mandatory to
set the main switch to 0 (zero) and lock it with a padlock.
Remove pressure from the installation by disconnecting
the safety valve, and then lock it with a padlock.
PAE85T / Operating instructions - 41
