Technical Data

Literature
Packaged weight
Dimensions
Display
Enclosure
Approvals
Ambient conditions
Environmental
Power supply
Relays
Humidity sensor
RH Output
Temperature sensor
Optional sensors
Communications
Mobile app
Languages
Warranty
Invita WiFi Thermostat 564
®
Submittal, Installation Operation Manual, User Manual, Job Record
1.3 lb. (600 g)
Display: 41/2" H x 23/4" W x
HVAC Interface Module: 7
3.5" color touchscreen
Display: White or Black PVC plastic, NEMA type 1
HVAC Interface Module: Blue PVC plastic, NEMA type 1
Meets Class B: ICES & FCC Part 15
Display: Indoor use only, -4 to 122°F (-20 to 50°C), RH ≤90% non-condensing
HVAC Interface Module: -40 to 122°F (-40 to 50°C), RH ≤90% non-condensing,
outdoor use requires mounting in a NEMA 3 enclosure
Do not use in presence of ammonia (animal barns).
21-30 V (ac), 6 VA, Class 2
30 V (ac) 2 A, Class 2 Circuits
0 to 90% ±4% RH
3.3 V (dc) humidity sensor power, 3.0 mA maximum
NTC thermistor, 10 kΩ @ 77°F (25°C ±0.2°C) ß=3892
tekmar type # 070, 072, 073, 076, 077, 079, 084, 086, 087
WiFi 802.11n, 2.4 GHz, WPA2 encryption
Apple iOS 11 or higher, Android 5 or higher
English/Français/Español
3 Year Limited Warranty
⁄ " D (114 x 70 x 14 mm)
9
16
⁄ " H x 4 ⁄ " W x 11/4" D (188 x 112 x 31 mm)
7 7
16 16
35
